TP-LinkNetwork Switches
Omada 5Port 10G MultiGigabit Desktop SwitchPORT: 5 10G RJ45 PortsSPEC: Desktop Steel CaseFEATURE
- Five 10 Gbps Ports. 5× 10-Gigabit ports unlock the highest performance of your 10G/Multi-Gig bandwidth and devices, and provide up to 100 Gbps of switching capacity
- Lightning-Fast Connections. Provides lightning-fast connections to 10G NAS, Server, 10G PCIe Adapter/ NIC, gaming computer, 2.5G/5G/10G WiFi 6 AP, 8K video, and more
- Ideal for Various Scenarios. Built for lightning-fast connections in LAN parties, home entertainment, small and home offices, and workstations
- Optimal 5-Speed Connections. Auto-negotiation for 5-speed (100Mbps/1G/2.5G/5G/10G) connections provide optimal performance
- Silent Operation. The revolutionary fanless design ensures unprecedented silent operation, ideal for any home or business
- Durable Metal Casing. Durable metal casing, desktop/wall-mounting, and professional heat dissipation design are well suited for different environments
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Omada 5Port 10G MultiGigabit Desktop SwitchPORT: 5 10G RJ45 PortsSPEC: Desktop Steel CaseFEATURE: Plug and Play
Specifications
Management features
- Switch type
- Unmanaged
- Quality of Service (QoS) support
- Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity
- 5
- Basic switching RJ-45 Ethernet ports type
- 10G Ethernet (100/1000/10000)
- Power connector
- DC-in jack
Network
- Networking standards
- IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
- 10G support
- Yes
- Copper ethernet cabling technology
- 10GBASE-T, 100BASE-TX, 1000BASE-T
- Flow control support
- Yes
- Auto MDI/MDI-X
- Yes
- Ethernet LAN data rates
- 10,100,1000,2500,5000,10000 Mbit/s
- Auto-negotiation
- Yes
Data transmission
- Switching capacity
- 100 Gbit/s
- Forwarding rate
- 74.4 Mpps
- MAC address table
- 16000 entries
- Store-and-forward
- Yes
- Jumbo frames support
- Yes
- Jumbo frames
- 12
- Packet buffer memory
- 12 MB
Security
- IGMP snooping
- Yes
Multicast features
- Multicast support
- Yes
Design
- Product colour
- Black
- Housing material
- Metal
- Reset button
- Yes
- LED indicators
- Activity, Link, Power
- Wall mountable
- Yes
Performance
- Plug and Play
- Yes
- Fanless
- Yes
Power
- Power source
- AC
- Power supply included
- Yes
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50/60 Hz
- DC input voltage
- 12 V
- Input current
- 2 A
- Power consumption (max)
- 25.19 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE)
- No
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -40 - 70 °C
- Operating relative humidity (H-H)
- 10 - 90%
- Storage relative humidity (H-H)
- 5 - 90%
- Heat dissipation
- 85.65 BTU/h
Weight & dimensions
- Width
- 226 mm
- Depth
- 131.2 mm
- Height
- 35 mm
Packaging content
- Cables included
- Power
- User guide
- Yes
Packaging data
- Rubber feet
- Yes
Certificates
- Compliance certificates
- CE, EAC, Federal Communications Commission (FCC), Industry Canada (IC), RoHS, UKCA
