7-Slot Unmanaged Media Converter Chassis for MCM Media Converter Series, Full Power Isolation
- Integrate up to 7 media converters in one 10in rack-mount chassis for simplifying network organization and expanding connectivity in enterprise and data center environments
- For MCM Media Converter Series
- Single power supply runs all seven converters
- Hot-swappable bays enable tool-free changes without downtime streamlining maintenance and accelerating edge changes
- Over-voltage protection and FCC CE UL and TAA compliance
- All-metal chassis with dual cooling fans and front LED monitoring
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Add a powered 7-slot rack that organizes edge converters, cuts clutter, and supports optional power redundancy for uptime.
The 7-Slot Media Converter Chassis delivers high-density, centralized management for up to seven media converters in a compact 10-inch rack-mount form. Designed for enterprise, telecom, and data center networks, it streamlines power distribution, reduces clutter, and supports nonstop operation with an optional hot-swappable Redundant Power System (RPS). the chassis is designed for the MCM Media Converter Series.
Centralized, Scalable Integration
Accommodates Fast, Gigabit, and 10-Gigabit Ethernet, VDSL2, and Serial-over-Ethernet converters in one chassis. Each slot is hot-swappable and independently powered, allowing upgrades or replacements without downtime.
Reliable Power and Protection
Includes one AC power supply with an optional AC or -48V DC backup for continuous service. Electrical isolation and protection against over-voltage, over-current, and short-circuit events ensure stable performance.
Durable, Intelligent Design
This rugged metal chassis with dual cooling fans and LED indicators provides efficient heat management and easy status monitoring. FCC, CE, and UL certified, the chassis offers long-term reliability in mission-critical environments.
Specifications
Technical details
- Rack mounting
- Yes
- LED indicators
- Fan, Power
- Material
- Metal
- Number of slots
- 7
- Product colour
- Black
- Mean time between failures (MTBF)
- 50000 h
- Compliance certificates
- CE, Federal Communications Commission (FCC), RoHS, Trade Agreements Act (TAA)
- Compatible products
- MCM Series
Power
- AC input voltage
- 100 - 240 V
- Output voltage
- 48 V
- Output current
- 4.2 A
- Included power plug types
- EU, NA, UK
Operational conditions
- Operating temperature (T-T)
- 0 - 50 °C
- Storage temperature (T-T)
- -40 - 70 °C
- Operating relative humidity (H-H)
- 5 - 90%
Weight & dimensions
- Width
- 417 mm
- Depth
- 140 mm
- Height
- 88.5 mm
Packaging data
- Cables included
- AC
- Manual
- Yes
- Package width
- 216 mm
- Package depth
- 316 mm
- Package height
- 153 mm
- Package weight
- 2.6 kg
Logistics data
- Master (outer) case width
- 405 mm
- Master (outer) case length
- 465 mm
- Master (outer) case height
- 360 mm
- Products per master (outer) case
- 5 pc(s)
