Rackmount PDU with 16 Outlets and Surge Protection - 1U
- Organize and add additional power outlets to your rack solution
- Compatible with StarTech.com 4POSTRACKBK
- 1U Server Rack PDU/Rackmount Power Distribution Unit/16 Outlet Rack Mount Power Strip
- Integrated 6ft power cord
- LED indicators for ground and surge detection
- Illuminated power and reset switch
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Organize and add additional power outlets to your rack solution
This 16-outlet (120V 15A)(12A UL) Rack PDU delivers a cost-effective power distribution solution for your server rack/cabinet. The 1U PDU can be mounted horizontally in any server rack 4in in depth or greater, to provide sixteen 120V 15A power ports/outlets, and features a rugged steel casing to ensure maximum durability.
The front of the PDU features two LEDs that indicate proper ground and surge detection, while enabling you to control the power state with an illuminated power/reset switch.
To prevent costly breakdowns of connected devices, the rackmount PDU features a built-in circuit breaker and reset switch, ensuring dependable performance of vital equipment.
Specifications
Design
- PDU types
- Basic
- Rack capacity
- 1U
- Mounting
- Horizontal
- Housing material
- Steel
- Product colour
- Black
- On/off switch
- Yes
Ports & interfaces
- AC outlets quantity
- 16 AC outlet(s)
- Power plug
- NEMA 5–15
- AC outlet types
- NEMA 5–15
Features
- LED indicators
- Yes
- Cable length
- 1.8 m
Power
- Nominal input voltage
- 120 V
- Nominal output voltage
- 120 V
- Output voltage
- 125 V
- Load capacity
- 1800 VA
- Maximum input current per phase
- 15 A
- Maximum total current draw per phase
- 15 A
- Surge energy rating
- 1800 J
- Surge protection
- Yes
Certificates
- Compliance certificates
- CE, RoHS
Operational conditions
- Operating temperature (T-T)
- -5 - 45 °C
- Storage temperature (T-T)
- -25 - 65 °C
Weight & dimensions
- Width
- 95.5 mm
- Depth
- 483 mm
- Height
- 43 mm
- Weight
- 2.36 kg
Packaging content
- Manual
- Yes
Packaging data
- Package weight
- 2.2 kg
- Package width
- 516 mm
- Package depth
- 235 mm
- Package height
- 66 mm
Logistics data
- Master (outer) case width
- 541 mm
- Master (outer) case length
- 261 mm
- Master (outer) case height
- 412 mm
- Products per master (outer) case
- 6 pc(s)
