Epdu BA 38UA in: L1430P 24A 2P Out: 20XC13:6XC19:8X520R

Part # EBA200-10UPC 78668597469917 lb

Basic 0U Black
34 AC outlet(s) NEMA 5-20R, C13 coupler, C19 coupler
5760 W

Special orderPrice on request

Reply within 1 business day
Volume & business pricing
Shipping across Canada & US

Overview

Eaton Basic rack PDU, 0U, L14-30P input, 5.76 kW max, 120/240V, 24A, 10 ft cord, Split-phase, TAA compliant, Outlets: (8) 5-20R, (20) C13 Outlet grip, (6) C19 Outlet grip

Specifications

Design

PDU types: Basic
Rack capacity: 0U
Mounting: Vertical
Product colour: Black

Ports & interfaces

AC outlets quantity: 34 AC outlet(s)
Power plug: NEMA L14-30P
AC outlet types: NEMA 5-20R, C13 coupler, C19 coupler

Features

Cable length: 3 m

Power

Nominal input voltage: 120-240 V
AC input frequency: 50 - 60 Hz
Maximum current: 24 A
Maximum power: 5760 W

Operational conditions

Operating temperature (T-T): 0 - 60 °C
Operating temperature (T-T): 32 - 140 °F

Downloads

Product brochure (PDF)
