Rack PDU, Switched, 1U, 16A, 208/230V, (8)C13

Part # AP7921BUPC 731304331629Warranty: 2 years repair or replace8.6 lb

Metered, Switched 0U/1U Black
8 AC outlet(s) C13 coupler
3680 W

In stockPrice on request

Reply within 1 business day
Volume & business pricing
Shipping across Canada & US

Overview

This APC Switched Rack PDU power distribution unit has a wide range of standardized PDU features that increase network efficiency, manageability and functionality. The output and input connections are (8)C13. Network management capabilities allow you to configure and manage rack PDUs from remote locations. It has has a local current monitoring display that gives a visible warning in case of an overload. The remote individual outlet control provides real-time monitoring of connected loads. It has a multi-tier user access that enables you to restrict unauthorized use of outlets. This rack has a single input power source making it easy to install.

Specifications

Design

PDU types: Metered, Switched
Rack capacity: 0U/1U
Mounting: Horizontal/Vertical
Product colour: Black

Ports & interfaces

AC outlets quantity: 8 AC outlet(s)
Power plug: C20 coupler
AC outlet types: C13 coupler
Input connection type: IEC-320 C20

Features

Cable length: 2.5 m

Management features

Monitoring: Current, Power, Voltage
Outlet control: Lock-out, Recycle, Turn off, Turn on

Power

Nominal input voltage: 200-230 V
AC input frequency: 50 - 60 Hz
Maximum current: 16 A
Nominal output voltage: 208-230 V
Load capacity: 3680 VA
Maximum input current per phase: 16 A
Maximum total current draw per phase: 16 A
Maximum power: 3680 W

Certificates

Compliance certificates: RoHS
Certification: cUL Listed, CE, CSA, EN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, GOST, IRAM, MIC, UL 60950, UL Listed, VDE, VCCI, REACH
