ATENVideo Splitters
4-port HDMI Splitter support 4k2k
- Connects one HDMI source to four HDMI displays at the same time
- HDMI (3D, Deep Color, 4kx2k); HDCP 1.4 Compliant
- Supports resolutions of up to Ultra HD 4k x 2k
- Supports Dolby True HD and DTS HD Master Audio
- Long distance transmission – up to 15 m (24 AWG)
- Supports max. data rate of 10.2 Gbps
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
The VS184A HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to four displays at the same time. It supports all HDMI-enabled equipment, such as DVD players, satellite set-top boxes and all HDMI displays.
The VS184A HDMI Splitter is HDCP (High Bandwidth Digital Content Protection) compliant, making it effective for use with all HDMI displays in home theater applications, as well as in corporate, educational and commercial settings.
Specifications
Ports & interfaces
- Video port type
- HDMI
- Video in
- 1
- Video out
- 4x HDMI
- Video ports quantity
- 5
- Connector(s)
- 4
- DC-in jack
- Yes
Features
- Product colour
- Black
- Maximum resolution
- 4096 x 2160 pixels
- Full HD
- Yes
- 3D
- Yes
- Maximum operating distance
- 15 m
- Remote control included
- No
- Rack mounting
- Yes
- HDCP
- Yes
- Supported graphics resolutions
- 3840 x 2160, 4096 x 2160
Power
- AC input voltage
- 5.3 V
- Power consumption (typical)
- 6.02 W
- USB powered
- No
Weight & dimensions
- Dimensions (WxDxH)
- 200 x 80 x 25 mm
- Weight
- 470 g
Operational conditions
- Operating temperature (T-T)
- 0 - 50 °C
- Storage temperature (T-T)
- -20 - 60 °C
- Operating relative humidity (H-H)
- 0 - 80%
Technical details
- Resolution
- 4096 x 2160 pixels
- Connector type
- HDMI Type A Female
- Number of connectors
- 4
- Maximum cable length
- 15 m
- Maximum video resolution
- 4096 x 2160 pixels
Logistics data
- Harmonized System (HS) code
- 85176990
