2-Port HDMI Audio/Video Splitter 4Kx2K

Part # VS182AUPC 6727920043601.35 lb

Connects one HDMI source to two HDMI displays at the same time
HDMI (3D, Deep Color, 4kx2k); HDCP 1.4 Compliant
Supports resolutions of up to Ultra HD 4kx2k and 1080p Full HD
Supports Dolby True HD and DTS HD Master Audio
Long distance transmission – up to 15 m (24 AWG)
Supports up to 340MHz bandwidth for high performance video

Special orderPrice on request

Reply within 1 business day
Volume & business pricing
Shipping across Canada & US

Overview

The VS182A HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to two displays at the same time. It supports all HDMI-enabled equipment, such as DVD players, satellite set-top boxes and all HDMI displays.

The VS182A HDMI Splitter is HDCP (High Bandwidth Digital Content Protection) compliant, making it effective for use with all HDMI displays in home theater applications, as well as in corporate, educational and commercial settings.

Specifications

Ports & interfaces

Video port type: HDMI
Video in: 1 x HDMI Type A Female (Black)
Video out: 2x HDMI
Video ports quantity: 3
DC-in jack: Yes

Features

Product colour: Black
Housing material: Metal
Maximum resolution: 4096 x 2160 pixels
HD type: 4K Ultra HD
3D: Yes
Maximum operating distance: 15 m
Maximum refresh rate: 60 Hz
Bandwidth: 340 MHz
HDCP version: 1.4
HDCP: Yes
Supported graphics resolutions: 3840 x 2160, 4096 x 2160
Plug and Play: Yes
Supported video modes: 2160i, 2160p
LED indicators: Yes
Dolby technologies: DTS-HD Master Audio, Dolby TrueHD
Windows operating systems supported: Yes
Mac operating systems supported: Yes
Mac compatibility: Yes

Power

AC input voltage: 5 V
Power consumption (typical): 3.12 W

Weight & dimensions

Width: 80 mm
Depth: 125 mm
Height: 25 mm
Weight: 504 g

Packaging data

Quantity per pack: 1 pc(s)
Package width: 59 mm
Package depth: 239 mm
Package height: 160 mm
Package weight: 642 g

Packaging content

Manual: Yes
Cables included: HDMI
User guide: Yes
AC adapter included: Yes

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 0 - 80%
Storage relative humidity (H-H): 0 - 80%

Downloads

Product brochure (PDF)User manual (PDF)
