APCUninterruptible Power Supplies (UPSs)
Smart-UPS RT 5000VA RM 208V to 208/120V uninterruptible power supply (UPS) 5 kVA 4000 W
- 5 kVA 4000 W
- Sealed Lead Acid (VRLA)
- Black
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS overload condition or fault.
01
Scalable runtime
Allows additional run time to be quickly added as needed.
02
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
03
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
04
Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.
05
Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.
Specifications
Features
- Output power capacity
- 5 kVA
- Output power
- 4000 W
- Input frequency
- 50/60 Hz
- Emergency Power Off (EPO)
- Yes
- Noise level
- 55 dB
- Audible alarm(s)
- Yes
Battery
- Battery technology
- Sealed Lead Acid (VRLA)
- Typical backup time at full load
- 4.8 min
- Typical backup time at half load
- 15.1 min
- Battery recharge time
- 2.50 h
Design
- Cable length
- 3.05 m
- Product colour
- Black
- LED indicators
- Yes
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -15 - 45 °C
- Operating altitude
- 0 - 3000 m
- Non-operating altitude
- 0 - 15000 m
Certificates
- Certification
- CSA,FCC Part 15 Class A,UL 1778
Weight & dimensions
- Weight
- 58.1 kg
Other features
- Interface
- Smart-Slot
- Input connection type
- NEMA L14-30P
- Dimensions (WxDxH)
- 432 x 660 x 130 mm
- Output voltage note
- Configurable for 208 or 240 nominal output voltage
- Nominal input voltage
- 208 V
Downloads
