APCUninterruptible Power Supplies (UPSs)

Smart-UPS X 3000VA Rack/Tower LCD 100-127V with Network Card

Part # SMX3000LVNCUPC 731304292654Warranty: 3 years repair or replace (excluding battery) and 2 year for battery, optional e140 lb

3 kVA 2700 W
Waveform: Sine
7 AC outlet(s)
Sealed Lead Acid (VRLA)
Rackmount/Tower Black

In stockPrice on request

Reply within 1 business day
Volume & business pricing
Shipping across Canada & US

Overview

Intuitive LCD interface

Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.

High frequency design

Reduces or eliminates bulky transformers resulting in lighter units for ease of handling.

Auto recognition of external batteries

UPS recognizes when external battery packs are attached and automatically adjusts runtime.

Predictive replace battery date

Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.

Green mode

Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.

Energy meter

Provides actual kilowatt hours of usage for energy conscious users.

Outlet group control

Turn on/off, reboot or shut down select outlet groups to save dispatching technicians to remote locations (for UPSs with switched outlet groups).

Load shedding

Turn off select outlet groups in a pre-determined sequence to shed less critical equipment and conserve runtime (UPSs with switched outlet groups).

Pure sine wave output on battery

Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.

Multiple switched outlet groups

Multiple outlet groups that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.

Wide input voltage range

Designed for harsh electrical environments to save battery life.

StruxureWare Central compatible

Enables centralized management via StruxureWare Central.

Battery failure notification

Provides early-warning fault analysis on batteries enabling timely preventive maintenance

High online efficiency

Reduces utlility costs, generates less heat.

LED Indicators

Provide easy-to-read status of the unit and utility power conditions.

Specifications

Features

Output power capacity: 3 kVA
Output power: 2700 W
Waveform: Sine
Input operation voltage (min): 70 V
Input operation voltage (max): 153 V
Input frequency: 50/60 Hz
Surge energy rating: 540 J
Efficiency: 97.5%
Emergency Power Off (EPO): Yes
Output voltage Total Harmonic Distortion (THD): 5%
Noise level: 55 dB
Audible alarm(s): Yes

Ports & interfaces

AC outlet types: NEMA 5–15R, NEMA 5–20R, NEMA L5-30R
Power plug: NEMA 5-30P
AC outlets quantity: 7 AC outlet(s)
USB 2.0 ports quantity: 1

Battery

Battery technology: Sealed Lead Acid (VRLA)
Number of batteries supported: 1
Battery recharge time: 3 h

Design

Form factor: Rackmount/Tower
Rack capacity: 2U
Cable length: 2.44 m
Product colour: Black
Display type: LED
LED indicators: Yes

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -15 - 45 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 15000 m

Certificates

Compliance certificates: RoHS
Certification: BSMI, CSA, EN 50091-2, EN 55022 Class A, FCC Part 15 Class A, NOM, TUV, UL 1778, VCCI Class A REACH
