Home/Catalogue/APC/SURTD3000XLIM
Drag to turn · 5 views
APCUninterruptible Power Supplies (UPSs)
Smart-UPS RT 3000VA 230V - Marine
- Double-conversion (Online)
- 3 kVA 2100 W
- 10 AC outlet(s)
- Sealed Lead Acid (VRLA)
- Rackmount Black
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
High density, double-conversion on-line power protection with scalable runtime.
Specifications
Features
- UPS topology
- Double-conversion (Online)
- Output power capacity
- 3 kVA
- Output power
- 2100 W
- Input operation voltage (min)
- 100 V
- Input operation voltage (max)
- 280 V
- Input frequency
- 50/60 Hz
- Output operation voltage (min)
- 220 V
- Output operation voltage (max)
- 240 V
- Surge energy rating
- 480 J
- Efficiency
- 92%
- Crest factor
- 3:1
- Emergency Power Off (EPO)
- Yes
- Output voltage Total Harmonic Distortion (THD)
- 3%
- Noise level
- 55 dB
Ports & interfaces
- AC outlet types
- C13 coupler, C19 coupler
- AC outlets quantity
- 10 AC outlet(s)
- Number of output IEC jumpers
- 2
- Ethernet LAN (RJ-45) ports
- 1
Battery
- Battery technology
- Sealed Lead Acid (VRLA)
- Battery recharge time
- 2.5 h
Design
- Form factor
- Rackmount
- Rack capacity
- 3U
- Cable length
- 2.44 m
- Product colour
- Black
- LED indicators
- Yes
Operational conditions
- Operating temperature (T-T)
- 0 - 55 °C
- Storage temperature (T-T)
- -15 - 45 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage relative humidity (H-H)
- 0 - 95%
- Operating altitude
- 0 - 3000 m
- Non-operating altitude
- 0 - 15000 m
Certificates
- Compliance certificates
- RoHS
Weight & dimensions
- Width
- 130 mm
- Depth
- 660 mm
- Height
- 432 mm
- Weight
- 54.5 kg
Packaging data
- Package weight
- 63.6 kg
Logistics data
- Harmonized System (HS) code
- 85078000
Other features
- Dimensions (WxDxH)
- 130 x 660 x 432 mm
- Nominal output voltage
- 230 V
- Nominal input voltage
- 230 V
- Package dimensions (WxDxH)
- 603 x 980 x 347 mm
Downloads
