Intel i7-1260P OPS Slot-in PC for ViewSonic ViewBoard , Windows 11 Pro, 16GB DDR4, 512GB SSD
- POWERFUL PROCESSOR: Intel Core™ i7-1260P 2.1G Turbo boost 4.7G
- STUNNING IMAGES: Support 5K UHD resolution
- AMPLE MEMORY AND STORAGE: 16GB of memory and 512GB of storage SSD
- FASTER WIFI: WIFI 6
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
The ViewSonic VPC37-W55-G1 Windows slot-in PC delivers a full Windows experience for users of ViewSonic ViewBoard interactive displays. This slot-in PC module easily plugs into compatible displays and supports up to 5K resolution. With a powerful Intel i7 processor, and fast SSD, the VPC37-W55-G1 provides fast computing power and advanced security protection needed for educational and corporate environments. Flexible connectivity options include HDMI, USB 3.0 and Type-C ports, as well as Giga LAN RJ45 and integrated Wi-Fi 6 connection.
Powerful Intel Processor
Equipped with an Intel i7 processor, this slot-in PC provides smooth and quick performance needed for serious computing.
Stunning 5K Ultra HD Resolution
With support for resolutions up to 5K, this device enables you to enjoy stunning images on your ViewBoard interactive display.
Ample Storage
The slot-in PC can store and play hours and hours of high-definition multimedia content thanks to its 512GB of storage SSD.
Faster WiFi
The latest WiFi 6 standard delivers incredibly fast WiFi performance with internet speeds of up to several gigabits per second.
Versatile Compatibility
Based on an industry standardized interface - Open Pluggable Specification, this slot-in computing module is compatible with any OPS-compliant interactive or commercial display.
ViewSonic Software Suite
A suite of ViewSonic software is preloaded to boost your productivity and collaboration.
Safe and Reliable
Equipped with a range of features such as password protection, two-step authentication, data encryption and more, this device ensures that privacy and security standards are met to keep user data safe.
Specifications
Processor
- Processor manufacturer
- Intel
- Processor generation
- 12th gen Intel® Core™ i7
- Processor family
- Intel® Core™ i7
- Processor model
- i7-1260P
- Processor cores
- 12
- Processor boost frequency
- 4.7 GHz
- Processor cache
- 18 MB
- Processor cache type
- Smart Cache
- Thermal Design Power (TDP)
- 28 W
Memory
- Internal memory
- 16 GB
Storage
- Total storage capacity
- 512 GB
- Storage media
- SSD
Graphics
- On-board graphics card
- Yes
- On-board graphics card family
- Intel Iris Xe Graphics
- On-board graphics card model
- Intel Iris Xe Graphics
- On-board graphics card dynamic frequency (max)
- 1400 MHz
- On-board graphics card OpenGL version
- 4.6
- On-board graphics card 4K support
- Yes
- Discrete graphics card
- No
- Graphics card Open GL support
- Yes
Network
- Wi-Fi
- Yes
- Wi-Fi standards
- Wi-Fi 6 (802.11ax)
- Bluetooth
- Yes
- Bluetooth version
- 5.1
Ports & interfaces
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
- 1
- HDMI ports quantity
- 1
- HDMI version
- 2.0
- DisplayPorts quantity
- 1
- Ethernet LAN (RJ-45) ports
- 1
- Line-in
- Yes
- Headphone outputs
- 1
Performance
- Number of antenna connectors
- 2
Software
- Operating system installed
- Windows 11 Pro
- Operating system architecture
- 64-bit
Power
- DC input voltage
- 12-19 V
Operational conditions
- Operating temperature (T-T)
- -5 - 40 °C
- Storage temperature (T-T)
- -20 - 60 °C
- Operating relative humidity (H-H)
- 10 - 90%
Weight & dimensions
- Width
- 202 mm
- Depth
- 122.6 mm
- Height
- 30 mm
- Weight
- 600 g
- Package width
- 267 mm
- Package depth
- 192 mm
- Package height
- 72 mm
- Package weight
- 970 g
Technical details
- Compliance certificates
- Federal Communications Commission (FCC), cTUVus
