VHB-E Indoor
- An extreme narrow 1.74mm bezel-to-bezel design creates seamless visual experience
- 700 nit brightness and non-glare panel provide high visibility 24/7
- Wide viewing angles enable clear image presentation for more viewers in large spaces
- Picture enhancement technology delivers optimized visuals
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Always-on, space-saving solution with extreme-narrow bezels
See an immersive and dependable viewing experience, 24/7 with Samsung’s VHB-E series. The display’s slim depth and 700 nit brightness ensures highly visible images and legible messages in a wide range of locations from shopping malls to lobbies, meeting rooms, control rooms and more.
Transform any space with high impact visuals
The slender design and 70.4mm cabinet depth provide flexibility for installation and an extreme-narrow 1.74mm bezel-to-bezel width creates a seamless picture, opening endless possibilities for designing a captivating visual experience.1,
View content from any angle
Wide viewing angles mean content is easily visible even if viewers aren’t standing directly in front of the display. Audiences can get clear details and vivid colors regardless of where the screen is located.
Vibrant images in any light
Non-glare panels evenly distribute light across the screen to maintain vibrant and accurate content. Combined with a high contrast ratio and 24/7 operation, visuals are vivid and eye-catching any time of the day or night — regardless of ambient light.
Image enhancement
Samsung’s powerful picture enhancement technology ensures all content is vibrant and clear. With Picture Enhancer mode, color saturation and contrast are improved by adjusting the gamma curve. Using Black Equalizer mode, dark images are lightened, making details easier to see.
Comprehensive calibration to fit your needs
Multi-step factory tuning provides uniform brightness and color. Users can also fine-tune advanced settings with free powerful Color Expert Pro software. For quick and simple calibration, Color Expert Pro Mobile enables white balance adjustments for displays up to 3x3 using a mobile camera.
Advanced presentation, simplified operation
Utilizing daisy chain design through DisplayPort 1.2 or HDMI ports enables the display to present UHD content on multiple screens without an external graphic card. Samsung's UHD Signage Player Box streamlines functionality by combining the media player and content management software.
Industry standard-certified
The VHB-E series is EMC class B-compliant, meeting strict standards of electromagnetic wave emission, while IP5x certification protects the display against dust and other conditions. The display packaging also passed a rigorous 2-step, ISTA-certified test to minimize possible damage during delivery.4,
Specifications
Display
- Display diagonal
- 139.7 cm (55")
- Display resolution
- 1920 x 1080 pixels
- HD type
- Full HD
- Panel type
- IPS
- Aspect ratio
- 16:9
- Active display area (W x H)
- 680.4 x 1209.6 mm
- Pixel pitch
- 0.63 x 0.63 mm
- Display brightness
- 700 cd/m²
- Contrast ratio (typical)
- 1000:1
- Haze rate
- 28%
- Colour gamut
- 72%
- Operating hours (hours/days)
- 24/7
Design
- Placement supported
- Indoor
- Orientation
- Horizontal/Vertical
- Bezel width (side)
- 1.74 mm
- Bezel width (top)
- 1.3 mm
- Bezel width (bottom)
- 0.44 mm
- VESA mounting
- Yes
- Panel mounting interface
- 600 x 400 mm
Ports & interfaces
- HDMI ports quantity
- 2
- HDMI input ports quantity
- 2
- DVI-D ports quantity
- 1
- DisplayPorts quantity
- 1
- DisplayPorts in
- 1
- DisplayPorts out
- 1
- Ethernet LAN (RJ-45) ports
- 1
- RS-232C
- Yes
- USB port
- Yes
- USB ports quantity
- 1
- HDCP
- Yes
- HDCP version
- 2.2
- Audio input
- Yes
- Audio output
- Yes
Power
- Power consumption (typical)
- 186 W
- Power consumption (max)
- 250 W
- Power consumption (standby)
- 0.5 W
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50 - 60 Hz
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 10 - 80%
Sustainability
- Certification
- 60950-1, EMC
Weight & dimensions
- Width
- 1212.2 mm
- Depth
- 70.4 mm
- Height
- 683 mm
- Weight
- 19.5 kg
Packaging data
- Cables included
- AC, DisplayPort, RS-232
- Remote control included
- Yes
- Package width
- 1398 mm
- Package depth
- 257 mm
- Package height
- 844 mm
- Package weight
- 28.6 kg
Downloads
