24/7, IPS Panel Video Wall with Extreme Thin Bezel (3.5 mm Bezel to Bezel), No SoC
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Always-on, space-saving solution with extreme-narrow bezels
See an immersive and dependable viewing experience, 24/7 with Samsung’s VMB-U series. The display’s slim depth and 500 nit brightness ensures highly visible images and legible messages in a wide range of locations from shopping malls to lobbies, meeting rooms, control rooms and more.
Transform any space with high impact visuals
The slender design and 69.9mm (2.75 inches) cabinet depth provide flexibility for installation and an ultra-narrow 3.5mm bezel-to-bezel width creates a seamless picture opening endless possibilities for designing a captivating visual experience.
View content from any angle
Wide viewing angles mean content is easily visible even if viewers aren’t standing directly in front of the display. Audiences can get clear details and vivid colors regardless of where the screen is located.
Vibrant images in any light
Non-glare panels evenly distribute light across the screen to maintain vibrant and accurate content. Combined with a high contrast ratio and 24/7 operation, visuals are vivid and eye-catching any time of the day or night—regardless of ambient light.
Image enhancement
Samsung’s powerful picture enhancement technology ensures all content is vibrant and clear. With Picture Enhancer mode, color saturation and contrast are improved by adjusting the gamma curve. Using Black Equalizer mode, dark images are lightened, making details easier to see.
Comprehensive calibration to fit your needs
Multi-step factory tuning provides uniform brightness and color. Users can also fine-tune advanced settings with free powerful Color Expert Pro software. For quick and simple calibration, Color Expert Pro Mobile enables white balance adjustments for displays up to 5x5 using a mobile camera.
Advanced presentation, simplified operation
Utilizing daisy chain design through DisplayPort 1.2 or HDMI ports enables the display to present UHD content on multiple screens without an external graphic card. Samsung's UHD Signage Player Box streamlines functionality by combining the media player and content management software.
Durable and user-friendly design
IP5x certified, the VMB-U series is dust-resistant and able to withstand a range of environmental conditions without needing to prepare additional enclosure in dusty places. An embedded, centrally located infrared receiver (IR) allows for easier and more flexible user control to the display.
Rigorous testing, robust protection
VMB-U series is delivered in specialized packaging which has passed a rigorous 4-step test to meet ISTA standards, ensuring the display is protected from any potential damage during transit. This provides peace of mind for businesses that the display is ready to function immediately after delivery.
Specifications
Display
- Display diagonal
- 139.7 cm (55")
- Display technology
- IPS
- Display resolution
- 1920 x 1080 pixels
- Display brightness
- 500 cd/m²
- HD type
- Full HD
- Native aspect ratio
- 16:9
- Contrast ratio (typical)
- 1200:1
- Pixel pitch
- 0.63 x 0.63 mm
- Active display area (W x H)
- 1209.6 x 680.4 mm
- Haze rate
- 25%
Ports & interfaces
- HDMI ports quantity
- 2
- HDMI version
- 2.0
- DVI port
- Yes
- DVI-D ports quantity
- 1
- DisplayPorts quantity
- 1
- USB port
- Yes
- USB ports quantity
- 1
- USB version
- 2.0
- Ethernet LAN (RJ-45) ports
- 1
- RS-232 interface
- Yes
- RS-232C
- Yes
Audio
- Built-in speaker(s)
- No
Design
- Product design
- Digital signage flat panel
- Placement supported
- Indoor
- Orientation
- Horizontal/Vertical
- Product colour
- Black
- VESA mounting
- Yes
- Panel mounting interface
- 600 x 400 mm
Performance
- Purpose
- Universal
- HDCP
- Yes
Power
- Power consumption (typical)
- 165 W
- Input voltage
- 100 - 240 V
- Power consumption (sleep)
- 0.5 W
Weight & dimensions
- Width
- 1213.5 mm
- Depth
- 73.1 mm
- Height
- 684.3 mm
- Weight
- 19.4 kg
Packaging data
- Package width
- 1398 mm
- Package depth
- 257 mm
- Package height
- 844 mm
- Package weight
- 27.6 kg
Packaging content
- Remote control included
- Yes
- Batteries included
- Yes
- Cables included
- AC
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 10 - 80%
