ViewSonicData Projectors

2,000 ANSI Lumens WXGA Short Throw LED Business/Education Projector.

Part # LS550WHUPC 7669070167417.95 lb

3rd generation LED technology with 30,000 hours lifespan
3,000 LED Lumens offering bright images in any environment
Instant power on/off for efficient use
0.49 short throw ratio for minima space consumption
360° projection and H/V keystone for easy installation
Comprehensive LAN control for efficient management

Special orderPrice on request

Reply within 1 business day
Volume & business pricing
Shipping across Canada & US

Overview

The LS550WH is ViewSonic’s first lamp-free high brightness WXGA short throw projector for business and education. Built with advanced 3rd generation LED technology, the LS550WH provides 3,000 LED Lumens and eliminates frequent lamp replacement and toxic mercury for a safer and greener environment, offering a phenomenal lifespan of 30,000 hours, less power consumption, true-to-life colours with 125% Rec.709, and instant power on/off capability for efficient use. The 0.49 short throw lens provides a 100” screen from just 1.06m away, delivering exceptional space efficiency and freeing presenters from blinding lights. Installation and setup are hassle-free with 360° tilt angle projection, H/V Keystone, and 4 corner adjustment capabilities while its comprehensive LAN control eases multiple device management and is compatible with Crestron, AMX, Extron, PJ Link, ATEN, and ViewSonic’s vController.

Advanced 3rd LED Technology

The latest 3rd generation LED technology eliminates toxic mercury and the cost and effort of frequent lamp replacement, offering consistently impressive brightness for up to 30,000 hours.

Higher Power Efficiency

Adopting ams OSRAM’s Ostar Projection Power LED technology, the LS550WH saves nearly 50% less energy than competing lamp-based projectors.

Cinema SuperColor+™ Technology

Impress any audience with ViewSonic’s exclusive Cinema SuperColor+™ Technology, covering 125% Rec.709 wide colour gamut for a rich, true-to-life colour experience.

Efficient Instant Power On/Off

Eliminate waiting times before and after use with instant power on/off capability, delivering immediate full brightness for timely starts with no cooling period required.

Enhanced Brightness for Business/Education Environments

With the latest LED technology, the LS550WH achieves a major brightness breakthrough to 3,000 LED Lumens, ensuring bright and detailed images in dim or lit environments.

Big Screen Fits for Small Spaces

The LS550WH's 0.49 short throw projection gives you 100” from only 1.06m distance when positioning the projector. Presenters will stay clear of the projector beam, eliminating eye glare and shadows on the projection screen.

Effortless Image Adjustment

Horizontal and Vertical Keystone correction along with 4 corner adjustment features eliminate crooked or distorted images for a perfectly proportioned picture every time.

360° Projection for Versatile Application

The projector can freely rotate at any angle vertically to aid with creative applications, allowing projection onto ceilings, walls, or angled signage.

Centralised Control for Management Efficiency

This projector comes equipped with Crestron, AMX, Extron and ViewSonic vController, an easy-to-use network management tool.

A Simpler Way to Update Projector Software

Skip trips to the service centre by keeping software up to date easily and onsite via USB cable connection with your laptop.

USB Type A Power Supply

The built-in 5V/2A USB output conveniently delivers power to HDMI wireless dongles, eliminating the need for separate power adaptors when streaming multimedia content.

Sealed Optical Engine with IP5X

Maintain crystal-clear image quality and product longevity with an advanced sealed optical engine that prevents dust from entering and affecting the thermal system.

Specifications

Projector

Supported aspect ratios: 4:3, 16:10, 16:9
Screen size compatibility: 1524 - 7620 mm (60 - 300")
Projection distance: 0.63 - 1.58 m
Projector brightness: 2000 ANSI lumens
Projection technology: LED
Projector native resolution: WXGA (1280x800)
Contrast ratio (typical): 3000000:1
Native aspect ratio: 16:10
Number of colours: 1.07 billion colours
Horizontal scan range: 15 - 102 kHz
Vertical scan range: 23 - 120 Hz
Keystone correction, horizontal: -40 - 40°
Keystone correction, vertical: -40 - 36°

Light source

Light source type: LED
Service life of light source: 30000 h

Lens system

Zoom capability: Yes
Zoom type: Fixed
Throw ratio: 0.49
Offset: 110%

Video

Supported graphics resolutions: 640 x 480 (VGA), 1920 x 1080 (HD 1080)
Supported video modes: 480i, 480p, 576i, 720p, 1080i, 1080p

Ports & interfaces

HDMI connector type: Full-size
HDMI version: 1.4
USB 2.0 Type-A ports quantity: 1
Serial interface type: RJ-45, RS-232
PC Audio in: Yes
PC Audio out: Yes
HDMI ports quantity: 1
DVI port: No
AC (power) in: Yes

Network

Smart TV: No
Ethernet LAN: Yes
Ethernet LAN (RJ-45) ports: 1
Wi-Fi: No

Storage

Card reader integrated: No

Features

Interactive: No
Noise level (economic mode): 26 dB
HDCP: Yes
On Screen Display (OSD): Yes
On Screen Display (OSD) languages: Arabic, Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, INC, Indonesian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese
Number of OSD languages: 24
Noise level: 30 dB
