9PX 2000 RT LV
- Double-conversion (Online)
- 2 kVA 1800 W
- Waveform: Pure sine
- 7 AC outlet(s)
- Sealed Lead Acid (VRLA)
- Rackmount/Tower Black
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Business continuity for edge computing
When you need flexible protection for equipment in IT racks, network closets and mission-critical applications, look no further than the Eaton® 9PX UPS. Providing solutions that are reliable,
versatile, powerful and efficient, the 9PX integrates seamlessly
into just about any environment.
With double-conversion topology for constant power conditioning and ENERGY STAR qualification, the 9PX supports your overall goal of business continuity. It’s also built for scalable deployment and features a graphical LCD interface that enables local access to configurations and settings, history and diagnostics, energy consumption and load segment control.
Take a closer look
As a stand-alone, online double-conversion UPS, 9PX rack/ tower (RT) models can withstand harsh electrical environments for a variety of critical applications including IT, edge networks, industrial automation, healthcare and K-12. For edge networks and on-premise installations, Eaton focuses on integration within the virtualized environment. This means you can improve your infrastructure performance through virtual machine (VM) centric management, disaster recovery and validated integration capabilities.
The right 9PX solution may also include a software client that supports 2N (or N+1) UPS-protected graceful shutdown, a maintenance bypass to keep loads running during UPS replacement, or a rack to organize all of your IT equipment and cabling. It’s all about ensuring seamless integration and compatibility.
Specifications
Features
- UPS topology
- Double-conversion (Online)
- Output power capacity
- 2 kVA
- Output power
- 1800 W
- Waveform
- Pure sine
- Input operation voltage (min)
- 100 V
- Input operation voltage (max)
- 125 V
- Input frequency
- 40/70 Hz
- Output operation voltage (min)
- 100 V
- Output operation voltage (max)
- 125 V
- Output frequency
- 50/60 Hz
- Response time
- 0 ms
- Number of input phases
- 1
- Efficiency
- 91%
- Output voltage Total Harmonic Distortion (THD)
- 3%
- Input current Total Harmonic Distortion (THD)
- 3%
- Noise level
- 47 dB
- Surge protection
- Yes
- Surge protection features
- Network
- Web-based management
- Yes
- Auto-restart
- Yes
Ports & interfaces
- AC outlet types
- NEMA 5–20R, NEMA L5-20R
- Power plug
- NEMA 5-20P
- AC outlets quantity
- 7 AC outlet(s)
- USB port
- Yes
- USB 2.0 ports quantity
- 1
- Serial interface
- Yes
- Serial interface type
- RS-232
- RS-232 ports
- 1
Battery
- Battery technology
- Sealed Lead Acid (VRLA)
- Hot-swap battery
- Yes
- Automatic battery test
- Yes
- Cold start
- Yes
Design
- Form factor
- Rackmount/Tower
- Rack capacity
- 2U
- Cable length
- 2.44 m
- Product colour
- Black
- Display type
- LCD
- LED indicators
- Yes
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- 0 - 35 °C
- Operating relative humidity (H-H)
- 0 - 96%
- Storage relative humidity (H-H)
- 0 - 96%
- Operating altitude
- 0 - 3000 m
Certificates
- Compliance certificates
- RoHS
Packaging content
- Rack mount kit
- Yes
- Cables included
- RS-232, USB cable
- Management card included
- No
- Manual
- Yes
Safety regulation & standards
- Safety
- IEC/EN 62040-1, UL 1778, CSA 22.2
Sustainability
- Sustainability certificates
- ENERGY STAR
Weight & dimensions
- Width
- 440 mm
- Depth
- 605 mm
- Height
- 86.5 mm
- Weight
- 27.9 kg
Packaging data
- Bracket
- Yes
- Package type
- Box
Logistics data
- Harmonized System (HS) code
- 85078000
Other features
- Nominal output voltage
- 120 V
- Nominal input voltage
- 120 V
