16-port HDMI KVM Switch

Part # CS17916UPC 67279200557212.46 lb

One USB console controls up to sixteen HDMI interface computers and two additional USB 2.0 devices
HDMI compatible
Cascadable to two levels–control up to 256 computers1
Multi-Display feature – stack up to eight CS17916 units and display video from up to eight monitors(dual display/triple display/quad display/multi-display)
2-port USB 2.0 hub built in2
Computer selection via front panel pushbuttons, hotkeys, and multilingual on-screen display (OSD)

Special orderPrice on request

Reply within 1 business day
Volume & business pricing
Shipping across Canada & US

Overview

The CS17916 16-port USB HDMI KVM Switch is a multi-purpose appliance that consolidates access and control of up to 16 HDMI computers from a single USB keyboard, USB mouse, and monitor console. The CS17916 can be cascaded up to two levels – up to 256 computers – all from a single console.

In addition, the CS17916 features multi-display functionality, which enables the use of standard USB cables to stack up to 8 switches in a multi-display installation where each computer is fitted with multiple video cards. It allows users to contrast, analyze and monitor video output in convenient ways, substantially simplifying the working environment.

The CS17916 supporting ATEN’s on-screen display (OSD) function, allowing it to access any computer connected to the installation, which offers OSD configuration backup / restore functions to save or back up the OSD settings and restore them as needed. The CS17916 provides multimedia keyboard support and is audio enabled. Users can listen to the audio output of each computer on two sets of speakers (on a one at- a-time basis).

Specifications

Ports & interfaces

Number of computers controlled: 256
Keyboard port type: USB
Mouse port type: USB
Video port type: HDMI
HDMI ports quantity: 2
Console ports: 3.5mm headphone, HDMI, USB A
Console USB ports quantity: 2
USB connector type: USB Type-A
Audio connections: Yes
DC-in jack: Yes

Performance

HD type: WUXGA
Maximum resolution: 1920 x 1200 pixels
Video bandwidth: 60 Hz
Scan interval: 1,255 s
HDCP: Yes
Hot-Plug support: Yes
Firmware upgradeable: Yes

Design

Rack mounting: Yes
Rack capacity: 1U
Product colour: Black
Housing material: Metal
Cascadable: Yes
LED indicators: Yes
Push button: Yes
Hot keys: Yes
Keyboard language: Chinese Traditional, English, French, German, Greek, Hungarian, Italian, Japanese, Korean, Russian, Spanish, Swedish, Swiss, UK English, US English
