APCUninterruptible Power Supplies (UPSs)
Smart-Ups 750VA 120V Shipboard
- 750VA load capacity, work without any interruption during power outages
- Up to 5 minute runtime on full load to preserve critical data from power shortage interruptions
- Provides enhanced protection in shipboard environments
- Provides quick access and control of the UPS in case of an emergency
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
The APC Smart-UPS 750VA 120V Shipboard (SMT750X93) is a robust and reliable uninterruptible power supply (UPS) designed specifically for marine and shipboard applications. This UPS ensures continuous power supply during outages, protecting critical equipment and preserving data integrity.
Specifications
Features
- UPS topology
- Line-Interactive
- Output power capacity
- 0.75 kVA
- Output power
- 500 W
- Waveform
- Sine
- Input operation voltage (min)
- 82 V
- Input operation voltage (max)
- 144 V
- Input frequency
- 50/60 Hz
- Output operation voltage (max)
- 120 V
- Output frequency
- 50/60 Hz
- Surge energy rating
- 593 J
- Response time
- 6 ms
- Number of input phases
- 1
- Number of output phases
- 1
- Single-phase input voltage supported
- 120 V
- Noise level
- 41 dB
- Audible alarm(s)
- Yes
Ports & interfaces
- AC outlet types
- NEMA 5-15R
- Power plug
- NEMA 5-15P
- AC outlets quantity
- 6 AC outlet(s)
- USB port
- Yes
- USB port type
- USB Type-B
Battery
- Battery replacement accessibility
- End-user
- Battery technology
- Sealed Lead Acid (VRLA)
- Battery capacity
- 172 Ah
- Typical backup time at full load
- 5 min
- Typical backup time at half load
- 15 min
- Battery life (max)
- 5 year(s)
- Battery recharge time
- 3 h
Design
- Form factor
- Tower
- Product colour
- Black
- Control type
- Buttons
- Display type
- LED
- LED indicators
- Yes
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -20 - 55 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage relative humidity (H-H)
- 0 - 95%
- Operating altitude
- 0 - 3000 m
- Non-operating altitude
- 0 - 15000 m
Technical details
- Sustainable packaging
- No
- Packaging recycled materials
- Recycled cardboard
- SCIP number
- b2b22a56-41f2-497e-9ea6-cf093b3b8bd3
- Preferred mounting position
- no preference
- Take-back system
- No
- Packaging without single use plastic
- No
Certificates
- Waste Electrical and Electronic Equipment (WEEE) compliance
- Yes
- Compliance certificates
- RoHS, REACH, WEEE
- Certification
- CSA C22.2 No 107.1
Packaging content
- Manual
- Yes
Sustainability
- Doesn't contain
- Mercury
Weight & dimensions
- Width
- 138 mm
- Depth
- 369 mm
- Height
- 161 mm
- Weight
- 12.5 kg
Packaging data
- Package width
- 499 mm
- Package depth
- 278 mm
- Package height
- 301 mm
- Package weight
- 14 kg
Logistics data
- Customs product code (TARIC)
- 8504409590
- Total carbon footprint (kg of CO2e)
- 548.4165222831
- Warranty period
- 3 year(s)
- Country of origin
- United States
Other features
- Input connection type
- NEMA 5-15P
- Output connection type
- 6 NEMA5-15R
- Output voltage
- 120 V
- Mounting
- front
