APCPower Distribution Units (PDUs)
Step down Transformer 10KVA power distribution unit (PDU) Black
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Rack-Mountable
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
01
Transformer for Step-down or Step-up or Isolation
Step down transformer placed upstream of the UPS to avoid inrush current and saturation eliminating need to oversize transformer
02
Heavy duty design
The Vault Lock’s heavy duty hardened steel construction provides the highest degree of portable tampering protection available on the market.
Specifications
Design
- Product colour
- Black
Ports & interfaces
- Input connection type
- Hard Wire 3-wire (2PH + G)
- Output connections
- 1x Hard Wire 3-wire (2PH + G) 1x Hard Wire 4-wire (2PH + N +G) 2x NEMA L14-30R 2x NEMA L5-20R
Power
- Nominal input voltage
- 208 V
- Load capacity
- 10000 VA
- Maximum input current per phase
- 60 A
- Maximum total current draw per phase
- 60 A
Certificates
- Certification
- C-tick,CE,CSA,GOST,UL Listed,VDE
Operational conditions
- Operating temperature (T-T)
- 0 - 45 °C
- Storage temperature (T-T)
- -25 - 65 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage relative humidity (H-H)
- 0 - 95%
Weight & dimensions
- Width
- 432 mm
- Depth
- 749 mm
- Height
- 175 mm
- Weight
- 100 kg
Downloads
