series HDMI Extension Cable w Active Signal Booster/Repeater M/F 8K60Hz HDR 4:4:4 HDCP 2.3 20ft
- Supports UHD resolutions up to 8K @ 60 Hz (4:4:4) for heightened video quality
- Carries High Dynamic Range (HDR) signals for rich contrast and expanded color accuracy
- Complies with HDCP 2.3 standards to display up-to-date 8K video content
- Active repeater allows clean transmission without the expense of an external booster
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Extends Your Existing HDMI Cable Run by 20 ft.
The dependable P569-A20-MF-8K6 (M/F) connects to your existing HDMI cable to extend the run by 20 feet (6.1 meters). This allows you more flexibility in placing, for instance, a cable box or media server connected to an HDMI-enabled television, monitor or projector.
Transmits Crystal-Clear 4K Video with HDR and 4:4:4 Color
This extension cable supports Ultra HD 8K resolutions up to 7680 x 4320 at 60 Hz, as well as Dolby Digital audio, DTS and TrueHD. HDR (High Dynamic Range) provides a wide range of vibrant colors with richer contrast, brighter whites and deeper blacks that pop on your display. HDCP 2.3 encryption allows you to stream 8K content with no loss in resolution. This cable also supports uncompressed 4:4:4 chroma subsampling for top-level PC gaming or using your HDTV as a PC monitor.
Ready to Use Right from the Package, So You Can Plug and Play Immediately
The extension cable requires no software or external power. A built-in USB-A pigtail cable can be used if additional power is necessary. The active repeater allows you to connect two devices farther apart without the cost of an external signal booster. An audio return channel simplifies setups between displays and receivers.
Specifications
Features
- Cable length
- 6.1 m
- Connector 1
- HDMI Type A (Standard)
- Connector 2
- HDMI Type A (Standard)
- Connector 1 gender
- Female
- Connector 2 gender
- Male
- Connector 1 form factor
- Straight
- Connector 2 form factor
- Straight
- HDMI cable type
- Standard HDMI cable
- Product colour
- Black
- 3D
- No
- Supported graphics resolutions
- 7680 x 4320
- Dolby technologies
- DTS, Dolby Digital, Dolby TrueHD
- HDCP
- Yes
- HDCP version
- 2.2/2.3
- High Dynamic Range (HDR) supported
- Yes
- Maximum refresh rate
- 60 Hz
- AWG wire size
- 26/28
- Connector contacts plating
- Gold
- Cable type
- Round cable
- Cable jacket material
- Polyvinyl chloride (PVC)
- Bend radius (min)
- 9 cm
- Colour depth
- 36 bit
- Colour sampling
- 4:4:4
- Extended display identification data (EDID)
- Yes
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -15 - 50 °C
- Operating relative humidity (H-H)
- 0 - 85%
- Storage relative humidity (H-H)
- 0 - 85%
Certificates
- Compliance certificates
- CE, Federal Communications Commission (FCC), RoHS, UKCA, WEEE
Weight & dimensions
- Cable diameter
- 7.3 mm
Packaging data
- Package width
- 355.6 mm
- Package depth
- 12.7 mm
- Package height
- 431.8 mm
- Package weight
- 426.38 g
- Package type
- Polybag
- Quantity per pack
- 1 pc(s)
