Home/Catalogue/TP-Link/UH7020C
Drag to turn · 4 views
TP-LinkInterface Hubs
USB TypeC 7Port HubSPEC - 1 USBC Connector?1 HDMI 4K 60Hz Port?1 USBC PD 100W Port?1 SD + 1 TF up
- Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-C
- Hub interfaces: HDMI, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C
- Ports quantity: 7
- 5000 Mbit/s
- Card reader integrated MicroSD (TransFlash), SD
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Compact and Elegant Design
The self-storing design not only protects the port, but also but also improves portability. Aluminum alloy case and braided cable make UH7020C more durable. Bring you a better user experience.
01
Easy to Use with Plug & Play
Simply plug in and start using in seconds, thanks to driver-free install with Mac OS, Windows 11/10/8.1/8/7, Linux OS, iPadOS, iOS, Android, Chrome OS, and Nintendo OS.
Specifications
Ports & interfaces
- Host interface
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C
- Hub interfaces
- HDMI, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C
- Ports quantity
- 7
- Card reader integrated
- Yes
- Compatible memory cards
- MicroSD (TransFlash), SD
Features
- Data transfer rate
- 5000 Mbit/s
- Certification
- CE, FCC, RoHS, HDMI, BSMI
Weight & dimensions
- Width
- 127 mm
- Depth
- 40 mm
- Height
- 12.2 mm
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 10 - 90%
- Storage relative humidity (H-H)
- 5 - 90%
