TP-LinkNetwork Switches
Omada 18Port Gigabit Rackmount Switch with 16Port PoE+ PORT: 16 Gigabit PoE+ Ports, 2 Gigabit
- 16× Gigabit PoE+ RJ45 ports and 2× Combo Gigabit SFP slots
- High PoE power budget with up to 30 W for each PoE port and 250 W for all PoE ports
- Working with IEEE 802.3af/at compliant PDs
- Up to 250m data and power transmitting range under Extend Mode
- Priority mode for ports 1–4 to guarantees the quality of sensitive applications like video monitor
- Isolation Mode allows one-click client traffic separation for higher security and performance
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Omada 18Port Gigabit Rackmount Switch with 16Port PoE+ PORT: 16 Gigabit PoE+ Ports, 2 Gigabit NonPoE Ports, 2 Combo Gigabit SFP Slots SPEC: 802.3at/af, 250 W PoE Power, 1U 19inch Rackmountable Steel Case FEATURE: Plug and Play
Specifications
Management features
- Switch type
- Unmanaged
- Quality of Service (QoS) support
- Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity
- 16
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- SFP module slots quantity
- 2
- Power connector
- AC-in jack
Network
- Networking standards
- IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- 10G support
- No
- Copper ethernet cabling technology
- 10BASE-T, 100BASE-TX, 1000BASE-T, 1000BASE-X
- Flow control support
- Yes
- Auto MDI/MDI-X
- Yes
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Auto-negotiation
- Yes
- MAC address auto-learning supported
- Yes
- MAC address auto-aging supported
- Yes
Data transmission
- Switching capacity
- 36 Gbit/s
- Forwarding rate
- 26.78 Mpps
- MAC address table
- 8000 entries
- Jumbo frames support
- Yes
- Jumbo frames
- 10
- Packet buffer memory
- 4.1 MB
Design
- Rack mounting
- Yes
- Form factor
- 1U
- Product colour
- Black
- Housing material
- Metal
- LED indicators
- Activity, Link, PoE, Power
- Number of fans
- 2 fan(s)
Performance
- Plug and Play
- Yes
Power
- Power source
- AC
- Power supply included
- Yes
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50/60 Hz
- Power consumption (max)
- 293.34 W
Power over Ethernet (PoE)
- Power over Ethernet (PoE)
- Yes
- Power over Ethernet plus (PoE+) ports quantity
- 16
- Power over Ethernet (PoE) power per port
- 30 W
- Total Power over Ethernet (PoE) budget
- 250 W
Operational conditions
- Operating temperature (T-T)
- 0 - 50 °C
- Storage temperature (T-T)
- -40 - 70 °C
- Operating relative humidity (H-H)
- 10 - 90%
- Storage relative humidity (H-H)
- 5 - 90%
- Heat dissipation
- 1000.29 BTU/h
Weight & dimensions
- Width
- 440 mm
- Depth
- 180 mm
- Height
- 44 mm
Packaging content
- Cables included
- Power
- User guide
- Yes
- Rack mount kit
- Yes
Packaging data
- Rubber feet
- Yes
Certificates
- Compliance certificates
- CE, Federal Communications Commission (FCC), Industry Canada (IC), RoHS
