USB-C to Ethernet Adapter, 10GbE, Multi-Gigabit, USB 20Gbps, 10G/5G/2.5G/1G, Thunderbolt & USB4
- Adds a 10GbE RJ45 port with a simple USB-C connection enabling wired access to 1G / 2.5G / 5G / 10G networks with auto-negotiation
- Up to 10Gbps throughput on Windows 11 and macOS 27 using the Realtek RTL8159 controller and USB 3.2 Gen 2x2 with 20Gbps host bandwidth
- Supports Windows macOS Linux USB4 and Thunderbolt 5/4/3
- Fanless aluminum housing
- TPE USB-C cabling reduces port strain
- Reinforced RJ45 construction improves durability
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Upgrade to high-speed 10GbE network connectivity through your computer's USB-C port
This USB-C to 10GbE network adapter adds multi-gigabit RJ45 connectivity to laptops, desktops, mini PCs, and workstations, with 10G/5G/2.5G/1G auto-negotiation for existing network infrastructure. Handle large file transfers, backups, server maintenance, and network troubleshooting at up to 10Gbps. Standard RJ45 connectivity, VLAN tagging, and QoS support help integrate the adapter into segmented enterprise networks. Achieve up to 10Gbps throughput on Windows 11 and macOS 27 systems. The Realtek RTL8159 controller and USB 3.2 Gen 2x2 interface support high-bandwidth network tasks. For optimal performance, connect to a USB 3.2 Gen 2x2 host using Cat6a cabling. Standardize one adapter across compatible Windows, macOS, and Linux systems, including USB4 and Thunderbolt 5/4/3 hosts. Bus-powered operation simplifies deployment, while a visible MAC address supports pre-deployment provisioning. Support extended use with a fanless aluminum housing, heat sink, and thermal silicone for passive heat management. Reinforced RJ45 construction withstands repeated connections during deployments and IT support, while Wake-on-LAN enables remote maintenance.
Specifications
Ports & interfaces
- Connectivity technology
- Wired
- Host interface
- USB Type-C
- Interface
- Ethernet
- Ethernet LAN (RJ-45) ports
- 1
- USB connector form factor
- Straight
- USB version
- USB 3.2 Gen 2x2
Network
- Maximum data transfer rate
- 10000 Mbit/s
- Networking standards
- IEEE 802.3an, IEEE 802.3bz, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3i
- Ethernet LAN data rates
- 10000,5000,2500,1000,100,10 Mbit/s
- Wake-on-LAN ready
- Yes
- Full duplex
- Yes
- Jumbo frames support
- Yes
Design
- Component for
- PC/Laptop
- Product colour
- Black, Grey
- Internal
- No
- LED indicators
- Yes
Operational conditions
- Operating temperature (T-T)
- 0 - 45 °C
- Storage temperature (T-T)
- -10 - 70 °C
- Operating relative humidity (H-H)
- 10 - 85%
Packaging data
- Package width
- 57 mm
- Package depth
- 190 mm
- Package height
- 19 mm
- Package weight
- 90 g
Packaging content
- Manual
- Yes
Logistics data
- Master (outer) case width
- 205 mm
- Master (outer) case length
- 425 mm
- Master (outer) case height
- 260 mm
- Products per master (outer) case
- 80 pc(s)
Other features
- Housing material
- Aluminium
