Industrial Gigabit PoE Splitter - 90W High Speed Power over Ethernet PoE+++ Splitter - 12-48V DC

Part # POESLT1G48VUPC 065030889735Warranty: 2 Years0.8 lb

Power non-PoE devices using network infrastructure by splitting a PoE connection into RJ45 data and DC power
Power over Ethernet splitter supports IEEE 802.3af/at/bt allows PoE/PoE+/PoE++
12/16/24/48V DC (1.5A) pwr out on terminal block configured w/DIP switch
1Gbps |1x RJ45 PoE In |1x RJ45 Data Out |10/100/1000 Mbps Auto |4 pin terminal block pwr out |DIN/wall mountable
MTBF 600k +hrs @ 50C |Vibration/shock/free fall rated |IP-30 housing |Hardened temp -40 to 75C
2-year warr

Special orderPrice on request

Reply within 1 business day
Volume & business pricing
Shipping across Canada & US

Overview

Rugged PoE Splitter | 12-48V DC | IP-30 Aluminum Housing | 1.5A Power Output

Splits a PoE connection (max 90W) into separate data (RJ45) and DC power (terminal block) that can power any device that uses DC power between 12V-48VDC (1.5A). Power non-PoE devices using network infrastructure, where power is not available.

Power Non-PoE Devices

Perfect for using PoE to power older devices while also providing network access for monitoring and control applications. Applications include:

• Security (card swipe or proximity boxes)

• Environmental monitoring (temperature/moisture sensors)

• Telco (analog interface systems/conversion)

Straightforward Deployment

Supports IEEE 802.3af (PoE / Type 1), IEEE 802.3at (PoE+ / Type 2), and IEEE 802.3bt (PoE++ / Type 3) PoE inputs up to 90W and splits data and power. Power output via terminal block can be configured for 12/16/24/48V DC (1.5A).

The configuration is completed by DIP switches and the product can be wall or DIN rail mounted using the included hardware.

Designed for Harsh Environments

Industrial features include -40 C to 75 C operating temperature, IP-30 rated housing, vibration, shock, and free-fall standard testing.

Vibration: EN 60068-2-6

Shock: EN 60068-2-27

Free-Fall: EN 60068-2-32

600,000+ hours MTBF rating using Telcordia/Bellcore at 50 C for long-term reliability.

The POESLT1G48V is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Specifications

Network

Ethernet interface type: Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000 Mbit/s
Cabling technology: 10/100/1000Base-T(X)
Power over Ethernet (PoE): Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Auto MDI/MDI-X: Yes
Duplex system: Full
Supported network protocols: CSMA/CD
