10 -Pack 6ft (1.8m) Mini DisplayPort to DisplayPort 1.2 Cable, 4K x 2K UHD Mini DisplayPort to
- 10 pack 6ft Mini-DP to DisplayPort v1.2 cable supports 4Kx2K(3840x2400 60Hz, 2560x1600 120Hz)
- 21.6 Gbps bandwidth/HBR2/8Ch Audio/MST/GTC/3D Stereo
- Durable 32AWG cable w/flexible PVC strain relief prevents damage due to bends/rough use
- Latching DP connectors prevent accidental disconnection
- For home/office/boardroom/classroom use w/ laptop/workstation and UHD monitor/projector/large display
- Samsung/Sony/Dell/Apple TV
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Create a high-resolution 4k x 2k connection with HBR2 support between your Mini DisplayPort™-equipped laptop and a standard DP monitor
The 10 pack 6ft Mini DisplayPort™ to DisplayPort Adapter Cable, features a Mini DP male connector on one end, and a DP male connector on the other, allowing you to connect any Mini DisplayPort-equipped laptop (including the Mac® family of products) to an HDTV, monitor or projector that uses a standard DisplayPort connection.
The mDP to DP cable supports high resolutions of up to 4k x 2k (3840 x 2160) @ 60Hz with a maximum HBR2 bandwidth of 21.6 Gbps. The cable also supports Multi-Stream (MST) for daisy chaining multiple monitors and provides optional audio support.
This product is backed for life, including free lifetime 24/5 multi-lingual technical assistance.
Specifications
Features
- Connector 1 form factor
- Straight
- Connector 2 form factor
- Straight
- Connector contacts plating
- Gold
- DisplayPort version
- 1.2
- Maximum resolution
- 3840 x 2160 pixels
- Supported graphics resolutions
- 2560 x 1600 (WQXGA)
- Maximum refresh rate
- 120 Hz
- Cable length
- 2.8 m
- Connector 1
- DisplayPort
- Connector 2
- Mini DisplayPort
- Connector 1 gender
- Male
- Connector 2 gender
- Male
- Latching connectors
- Yes
- Product colour
- Black
- Cable rating
- CMG (CM)
- Cable shielding
- Aluminum mylar foil
- Jacket material
- Polyvinyl chloride (PVC)
- AWG wire size
- 32
- Bandwidth
- 21600 MB/s
- HBR3 support
- No
- Multi-Stream Transport (MST)
- Yes
- Number of conductors
- 19
Operational conditions
- Operating temperature (T-T)
- 0 - 45 °C
- Storage temperature (T-T)
- -10 - 70 °C
- Operating relative humidity (H-H)
- 10 - 85%
Certificates
- Compliance certificates
- RoHS
Sustainability
- Sustainability compliance
- Yes
Weight & dimensions
- Cable diameter
- 4.8 mm
- Weight
- 69 g
Packaging data
- Package width
- 228 mm
- Package depth
- 238 mm
- Package height
- 44 mm
- Package weight
- 700 g
Packaging content
- Quantity per pack
- 10 pc(s)
Logistics data
- Master (outer) case width
- 507 mm
- Master (outer) case length
- 332 mm
- Master (outer) case height
- 222 mm
- Products per master (outer) case
- 10 pc(s)
