Dual 2.5" SSD/HDD Mounting Bracket for 3.5” Drive Bay - Tool-Less Installation
- Install two 2.5" solid-state drives or hard drives into a single 3.5" bay in a desktop computer
- Tool-free 2-drive adapter bracket
- 2-bay 2.5" to 3.5" SATA SSD/HDD Converter Adapter
- Supports 2.5in drives 5mm to 12.5 mm in height
- SATA I/II/III
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Install two 2.5” solid-state drives or hard drives into a single 3.5” bay in a desktop computer
Install your drives in no time - with no tools required. This tool-less mounting bracket lets you mount two 2.5” solid-state drives or hard drives into a 3.5” bay in your desktop computer.
Easy, tool-less drive installation
The bracket design lets you quickly secure your drives into the mounting bracket, without using tools. Then you simply put the bracket into a 3.5” drive bay in your computer and hold it in place using the tool-less pegs.
Wide compatibility
Designed for versatility, the tool-less mounting bracket supports a wide range of 2.5” solid-state drives or hard drives, ranging from 5 to 12.5 mm in height.
Designed for trouble-free use
The lightweight mounting bracket is designed for trouble-free, reliable performance. BRACKET225PT is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Specifications
Features
- Size (imperial)
- 8.89 cm (3.5")
- Type
- Bezel panel
- Product colour
- Black
- Number of HDDs supported
- 2
- HDD size
- 2.5"
- HDD interface
- IDE/ATA, Serial ATA
- Material
- Plastic
- Certification
- CE, REACH
Weight & dimensions
- Width
- 100 mm
- Depth
- 132 mm
- Height
- 29.5 mm
- Weight
- 52 g
Packaging data
- Package width
- 141 mm
- Package depth
- 108 mm
- Package height
- 41 mm
- Package weight
- 81 g
Packaging content
- Quick start guide
- Yes
- Number of pegs
- 6
Technical details
- Compliance certificates
- RoHS
Logistics data
- Products per master (outer) case
- 60 pc(s)
- Master (outer) case width
- 451 mm
- Master (outer) case length
- 384 mm
- Master (outer) case height
- 247 mm
- Harmonized System (HS) code
- 84733080
Downloads
