Home/Catalogue/Samsung/LH46OMBEBGBXZA
Drag to turn · 12 views
SamsungSignage Displays
OM46B Digital signage flat panel 116.8 cm (46") LCD Wi-Fi 4000 cd/m² Full HD Black Tizen 5.0 24/7
- Digital signage flat panel Black
- 116.8 cm (46") 1920 x 1080 pixels LCD 4000 cd/m²
- 6 ms
- Ethernet LAN Wi-Fi
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
4000nit High Brightness, 24/7, Semi outdoor Usage, Quad Core, Tizen 5.0, IP5x
Specifications
Display
- Panel type
- VA
- Display diagonal
- 116.8 cm (46")
- Display technology
- LCD
- Display resolution
- 1920 x 1080 pixels
- Display brightness
- 4000 cd/m²
- HD type
- Full HD
- Touchscreen
- No
- Native aspect ratio
- 16:9
- Response time
- 6 ms
- Contrast ratio (typical)
- 6000:1
- Dynamic contrast ratio marketing name
- Mega Contrast
- Viewing angle, horizontal
- 178°
- Viewing angle, vertical
- 178°
- Pixel pitch
- 0.53 x 0.53 mm
- Colour saturation
- 72%
- Horizontal scan range
- 15 - 135 kHz
- Vertical scan range
- 24 - 75 Hz
- RGB colour space
- NTSC
Ports & interfaces
- HDMI ports quantity
- 2
- HDMI version
- 2.0
- HDMI input ports quantity
- 2
- DVI port
- No
- DisplayPorts quantity
- 1
- DisplayPorts in
- 1
- USB port
- Yes
- USB ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 2
- Composite video out
- 1
- RS-232 interface
- Yes
- RS-232C
- Yes
- Infrared data port
- Yes
Design
- Product design
- Digital signage flat panel
- Product colour
- Black
- VESA mounting
- Yes
- Panel mounting interface
- 400 x 400 mm
- Bezel width (bottom)
- 1.99 cm
- Bezel width (side)
- 1.99 cm
- Bezel width (top)
- 1.99 cm
Performance
- TV tuner integrated
- No
- Operating hours (hours/days)
- 24/7
- HDCP
- Yes
- International Protection (IP) code
- IP5X
- HDCP version
- 2.2
Power
- Power consumption (typical)
- 350 W
- Power consumption (sleep)
- 0.5 W
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50 - 60 Hz
Computer system
- Internal storage capacity
- 8 GB
- Operating system installed
- Tizen 5.0
Weight & dimensions
- Display width
- 1062 mm
- Display depth
- 54.5 mm
- Display height
- 616.6 mm
- Display weight
- 18.2 kg
Packaging data
- Package width
- 1189 mm
- Package depth
- 158 mm
- Package height
- 757 mm
- Package weight
- 23 kg
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 10 - 80%
Network
- Ethernet LAN
- Yes
- Wi-Fi
- Yes
Technical details
- Audio in (mini jack)
- No
Other features
- Audio output
- Stereo Mini Jack
- Bluetooth
- No
- Video out
- Yes
Downloads
