NETGEARNetwork Switches
GSM4230PX Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
- Managed L2/L3/L4 Web-based management
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 26
- MAC address table: 16000 entries Switching capacity: 132 Gbit/s
- Rack mounting
- PoE Power over Ethernet (PoE)
In stockPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Switching engineered for 1G AV over IP with rear-facing ports ensuring a clean integration in AV racks. Pre-configured for out of the box functionality!
01
Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.
02
Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.
03
Sleek, Quiet Design
Less fan noise, and mounting ears included for under-table or wall mounting.
04
Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4250 (and M4300) switches.
Specifications
Management features
- Switch type
- Managed
- Switch layer
- L2/L3/L4
- Quality of Service (QoS) support
- Yes
- Web-based management
- Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity
- 26
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- SFP+ module slots quantity
- 4
- USB 2.0 ports quantity
- 1
Network
- IPv4 routes
- 512
- IPv6 routes
- 128
- VLAN support
- Yes
- Virtual LAN features
- Private VLAN
- Number of VLANs
- 4000
Data transmission
- Switching capacity
- 132 Gbit/s
- Throughput
- 98.21 Mpps
- MAC address table
- 16000 entries
- Latency (1 Gbps)
- 2.29 µs
- Latency (10 Gbps)
- 0.83 µs
- Jumbo frames support
- Yes
- Jumbo frames
- 12000
- Packet buffer memory
- 16 MB
Multicast features
- Multicast support
- Yes
Design
- Rack mounting
- Yes
- Product colour
- Black
Performance
- Built-in processor
- Yes
- Processor model
- ARM Cortex-A57
- Noise level
- 42 dB
- Fanless
- Yes
Power
- Power source
- PoE
Power over Ethernet (PoE)
- Power over Ethernet (PoE)
- Yes
- Power over Ethernet plus (PoE+) ports quantity
- 24
- Power over Ethernet (PoE) power per port
- 30 W
- Total Power over Ethernet (PoE) budget
- 430 W
Weight & dimensions
- Width
- 440 mm
- Depth
- 400 mm
- Height
- 43.2 mm
- Weight
- 5.45 kg
Packaging content
- Cables included
- AC, LAN (RJ-45), USB Type-C
- User guide
- Yes
- Rack mount kit
- Yes
