EatonUninterruptible Power Supplies (UPSs)
Tower 5.70 Minute Standby 120 V AC Input 100 V AC, 110 V AC, 120 V AC, 125 V AC Output
- Double-conversion (Online)
- 3 kVA 2700 W
- Waveform: Pure sine
- Tower Black
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Eaton 9SX online, extended runtime UPS, 3000 VA, 2700 W, Hardwired input/output, 13.6"Hx8.4"Wx16.2"D, 77.2 lb., network card optional
Specifications
Features
- UPS topology
- Double-conversion (Online)
- Output power capacity
- 3 kVA
- Output power
- 2700 W
- Waveform
- Pure sine
- Input frequency
- 40/70 Hz
- Output operation voltage (min)
- 100 V
- Output operation voltage (max)
- 125 V
- Output frequency
- 50/60 Hz
- Power factor
- 0.9
- Input power factor
- 0.99
Ports & interfaces
- USB port
- Yes
- USB 2.0 ports quantity
- 1
- Serial interface
- Yes
- Serial interface type
- RS-232
- RS-232 ports
- 1
Battery
- Hot-swap battery
- Yes
Design
- Form factor
- Tower
- Product colour
- Black
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
Certificates
- Certification
- cULus Listed
Packaging content
- Cables included
- RS-232, USB cable
- Manual
- Yes
Weight & dimensions
- Width
- 213.4 mm
- Depth
- 411.5 mm
- Height
- 345.4 mm
- Weight
- 35 kg
Downloads
