Ultrawide Micro-Adjustable Static Wall Mount, Extra-Large Kit
- Integrated teardrop design speeds up wall plate installation by allowing pre-installation of the bolts to the wall
- ControlZone Leveling for post-installation fine tuning of height and leveling
- Centerless Shift provides up to 22.6" (575mm) of post-installation lateral shift for limitless centering
- Set screws keep the mount rigid, stable and secure throughout the life of the installation
- ClickConnect offers an audible click when the screen safely engages with the mount
- Built-in cable stand provides easy access under the screen
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
The Ultrawide Micro-Adjustable Static Wall Mount, Extra-Large Kit leverages Fusion® features to support displays with 21:9 aspect ratio and ultrawide mounting patterns (up to 1954 mm x 600 mm) in a secure, easy-to-install solution.
Integrated teardrop design speeds up wall plate installation by allowing pre-installation of the bolts to the wall
ControlZone Leveling for post-installation fine tuning of height and leveling
Centerless Shift provides up to 22.6" (575mm) of post-installation lateral shift for limitless centering
Set screws keep the mount rigid, stable and secure throughout the life of the installation
ClickConnect offers an audible click when the screen safely engages with the mount
Built-in cable stand provides easy access under the screen
A full line of accessories can be installed with the mount and the entire unit can be adjusted together
Multiple installation options for various stud distances
Exclusive nesting spacers can be stacked to achieve any depth
Quick-Store Cords use magnets to easily store and access pull cords
Improved cable management with new end caps
Integrated Security
Ships with a custom hardware kit that can be hung from mount rails if installing in stages
Easy Open box with less waste to throw away
Specifications
Mounting
- Maximum weight capacity
- 113.4 kg
- Minimum screen size
- 2.03 m (80")
- Number of displays supported
- 1
- Maximum weight capacity (per display)
- 113.4 kg
- Maximum screen size
- 3.05 m (120")
- Minimum VESA mount
- 1300 x 100 mm
- Maximum VESA mount
- 1954 x 600 mm
- Mounting type
- Wall
Ergonomics
- Cable management
- Yes
Design
- Product colour
- Black
Technical details
- Country of origin
- China
Weight & dimensions
- Width
- 495.3 mm
- Depth
- 57.1 mm
- Height
- 666.8 mm
- Weight
- 16.5 kg
Packaging data
- Package weight
- 16.5 kg
