ATENAV Extenders
HDMI Signal Booster
- Superior video quality – True 4k resolutions of 4096 x 2160 @ 60 Hz (4:4:4) video and standard 1080p (1920 x 1080 @ 60 Hz)
- HDMI (3D, Deep Color, 4K)
- Max. Data Rate 18 Gbps (6 Gbps Per Lane)
- HDMI and HDCP 2.2 compatible
- Supports up to True 4K resolutions when cascaded up to 10 levels
- - Up to 10 m True 4K transmission distance (max. 5 m on the input side and 5 m on the output side)
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
The VB800 is a True 4K HDMI booster providing a solution for long distance transmission. The HDMI booster reliably extends True 4K signals and can be cascaded up to 10 levels, guaranteeing ultimate color and image quality. The VB800 is HDMI compliant and supports all HDMI-enabled devices. The booster can be rack mounted, offering excellent flexibility for managing both work and home settings.
Specifications
Features
- Type
- AV transmitter & receiver
- Maximum transfer distance
- 20 m
- Supported graphics resolutions
- 1920 x 1080 (HD 1080)
- Bandwidth
- 18 Gbit/s
- Bandwidth
- 600 MHz
- HDCP
- Yes
- Material
- Metal
- Plug and Play
- Yes
- Product colour
- Black
Ports & interfaces
- HDMI in
- 1
- Number of HDMI outputs
- 1
- DC-in jack
- Yes
Power
- Power consumption (typical)
- 0.99 W
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -20 - 60 °C
- Operating relative humidity (H-H)
- 0 - 80%
Weight & dimensions
- Dimensions (WxDxH)
- 56 x 49 x 170 mm
- Weight
- 90 g
Packaging content
- Cables included
- AC
- Mounting kit
- Yes
Downloads
