ATENComputer Data Switches
4-port USB 3.0 Peripheral Sharing Device
- Enables 4 computers to share 4 USB 3.2 Gen1 devices
- Simple port selection via remote port selector for convenient switch placement
- USB 3.2 Gen1 compliant, supporting data transfer rates of up to 5 Gbps
- LEDs indicates which computer is active
- Over-current protection
- Multiplatform support – Windows, Linux and Mac
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
ATEN US434 is a 4-port USB 3.2 Gen1 peripheral sharing device that allows users to share four USB devices between 4 different computers. US434 is USB 3.2 Gen1 compliant, which can support data transfer rate up to 5Gbps and backwards compatible with USB 2.0 and USB1.1. It is perfect for high-bandwidth devices, such as USB docking stations or HD cameras.
01
1x US434 4 x 4 USB 3.2 Gen1 Peripheral Sharing Switch
2x LIN6-11C1-E11G USB 3.2 Gen1 Type-B to Type-A Cables (1,2m)
2x LIN6-11C1-E12G USB 3.2 Gen1 Type-B to Type-A Cables (1,8m)
1x Remote Port Selector
1x User Instructions
Specifications
Ports & interfaces
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity
- 4
- DC-in jack
- Yes
Performance
- Maximum data transfer rate
- 5 Gbit/s
- Remote control function
- Yes
- LED indicators
- Yes
- Power connector
- Micro-USB Type-B
- Product colour
- Black
- Housing material
- Plastic
Technical details
- Compliance certificates
- RoHS
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -20 - 60 °C
- Operating relative humidity (H-H)
- 0 - 80%
Weight & dimensions
- Width
- 36.6 mm
- Depth
- 93.7 mm
- Height
- 26.8 mm
- Weight
- 439 g
Packaging data
- Package depth
- 163 mm
- Package width
- 70 mm
- Package height
- 195 mm
- Package weight
- 576 g
Logistics data
- Products per master (outer) case
- 10 pc(s)
- Master (outer) case gross weight
- 6.46 kg
- Master (outer) case length
- 405 mm
- Master (outer) case width
- 395 mm
- Master (outer) case height
- 182 mm
- Master (outer) case net weight
- 4.39 kg
