ASUSPCs/Workstations

ROG NUC 760 Ultra 7 155H Fullt Scorpion

Part # RNUC14SRKU7168AUIUPC 1971054902911 lb

Windows 11 Home 64-bit
Intel Core Ultra 7 155H (24MB Cache)
NVIDIA GeForce RTX 4060 (8GB GDDR6)
16GB (5600MHz) DDR5-SDRAM (2 x 8) & 512GB SSD

Special orderPrice on request

Reply within 1 business day
Volume & business pricing
Shipping across Canada & US

Overview

ASUS NUC 14 Performance

Level Up. Embrace intelligence.

Experience the ASUS NUC 14 Performance, a compact powerhouse where efficiency meets raw power. This cutting-edge device is equipped with Intel® Core™ Ultra 9/7 processors and NVIDIA® GeForce RTX™ 4070 and 4060 graphics, delivering unparalleled performance and revolutionizing productivity. Stay connected seamlessly with flawless connectivity and enjoy lightning-fast response times. Its sleek design adds a touch of sophistication to any workspace. Elevate your computing experience to new heights with the ASUS NUC 14 Performance. Effortlessly upgrade your enterprise with this powerful machine that combines power, efficiency, and style.

Specifications

Processor

Processor manufacturer: Intel
Processor family: Intel Core Ultra 7
Processor generation: Intel® Core™ Ultra (Series 1)
Processor model: 155H
Processor cores: 16
Processor threads: 22
Processor boost frequency: 4.8 GHz
Performance cores: 6
Efficient cores: 8
Low Power Efficient-cores: 2
Performance-core Max Turbo Frequency: 4.8 GHz
Efficient-core Max Turbo Frequency: 3.8 GHz
Low Power Efficient-core Max Turbo Frequency: 2.5 GHz
Performance-core base frequency: 1.4 GHz
Efficient-core base frequency: 0.9 GHz
Low Power Efficient-core Base Frequency: 700 MHz
Processor cache: 24 MB
Processor cache type: Smart Cache
Number of processors installed: 1
Processor base power: 28 W
Maximum turbo power: 115 W

Neural processor unit (NPU)

Neural processor unit (NPU): Intel AI Boost
Maximum frequency NPU: 1.4 GHz
Sparsity support: Yes
Windows Studio effects support: Yes
AI software frameworks supported by NPU: DirectML, ONNX RT, OpenVINO, Windows ML

Memory

Internal memory: 16 GB
Maximum internal memory: 64 GB
Internal memory type: DDR5-SDRAM
Memory layout (slots x size): 2 x 8 GB
Memory slots: 2x SO-DIMM
Memory clock speed: 5600 MHz
Memory channels: Dual-channel

Storage

Total storage capacity: 512 GB
Storage media: SSD
Optical drive type: No
Number of storage drives installed: 1
Number of storage drives supported: 3
Total SSDs capacity: 512 GB
Number of SSDs installed: 1
SSD capacity: 512 GB
SSD interface: PCI Express 4.0
SSD form factor: M.2
Card reader integrated: Yes
Compatible memory cards: SD

Graphics

Discrete graphics card: Yes
Discrete GPU manufacturer: NVIDIA
On-board graphics card: Yes
Discrete graphics card model: NVIDIA GeForce RTX 4060
Discrete graphics card memory: 8 GB
Discrete graphics memory type: GDDR6
Number of discrete graphics cards: 1
On-board GPU manufacturer: Intel
On-board graphics card family: Intel Arc Graphics
On-board graphics card model: Intel Arc Graphics

Performance

Product type: Mini PC

Network

Ethernet LAN: Yes
Ethernet LAN data rates: 10,100,1000,2500 Mbit/s
Cabling technology: 10/100/1000Base-T(X)
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
WLAN controller manufacturer: Killer
Antenna type: 2x2
Bluetooth: Yes
Bluetooth version: 5.3

Ports & interfaces

USB 2.0 ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
Intel® Thunderbolt 4: Yes
Thunderbolt 4 ports quantity: 1
DisplayPorts quantity: 2
DisplayPort version: 1.4a
HDMI ports quantity: 1
HDMI version: 2.1
Ethernet LAN (RJ-45) ports: 1
Combo headphone/mic port: Yes
Headphone outputs: 1
DC-in jack: Yes

Design

Chassis type: Mini PC
Volume: 2.5 L
Cable lock slot: Yes
Cable lock slot type: Kensington
Product colour: Black

Software

Operating system architecture: 64-bit
Operating system installed: Windows 11 Home

Display

Display included: No

Audio

Audio chip: Realtek ALC256

Weight & dimensions

Width: 270 mm
Depth: 180 mm
Height: 50 mm
Weight: 2.6 kg

Downloads

Product brochure (PDF)User manual (PDF)
