Back-UPS 500VA uninterruptible power supply (UPS) 0.5 kVA 300 W 4 AC outlet(s)
- 0.5 kVA 300 W
- 4 AC outlet(s)
- Sealed Lead Acid (VRLA)
- Mini Tower Black
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Status Indicator LED's
Provides a quick visual indication of your unit's status.
Resettable circuit breaker
Easy recovery from overloads; no need to replace a fuse.
Boost Automatic Voltage Regulation (AVR)
Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Adjustable voltage-transfer points
Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Adjustable voltage sensitivity
Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Audible alarms
Provides notification of changing utility power and UPS conditions
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Lightning and Surge Protection
Protection from surges, spikes and even lightning is guaranteed!
Resettable circuit breaker
Instead of a hard to find fuse, there is a push-button circuit breaker for easy recovery from an overload or short circuit.
Audible alarms
Proactively notifies you of changing UPS and utility power conditions.
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Transformer Block Spacing
Designed to allow the use of up to two transformer block plugs without blocking access to other receptacles.
Specifications
Features
- Output power capacity
- 0.5 kVA
- Output power
- 300 W
- Input operation voltage (max)
- 230 V
- Input frequency
- 50/60 Hz
- Output operation voltage (max)
- 230 V
- Surge energy rating
- 240 J
- Number of input phases
- 1
- Number of output phases
- 3
- Surge protection
- Yes
- Audible alarm(s)
- Yes
Ports & interfaces
- AC outlet types
- C13 coupler
- Power plug
- C14 coupler
- AC outlets quantity
- 4 AC outlet(s)
Battery
- Battery technology
- Sealed Lead Acid (VRLA)
- Typical backup time at full load
- 70 min
- Typical backup time at half load
- 1 min
- Battery recharge time
- 10 h
Design
- Form factor
- Mini Tower
- Cable length
- 1.8 m
- Product colour
- Black
- LED indicators
- Power
Operational conditions
- Storage temperature (T-T)
- -15 - 45 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage relative humidity (H-H)
- 0 - 95%
- Operating altitude
- 0 - 3000 m
- Non-operating altitude
- 0 - 15000 m
Certificates
- Compliance certificates
- RoHS
Weight & dimensions
- Width
- 115 mm
- Depth
- 213 mm
- Height
- 185 mm
- Weight
- 4.9 kg
Packaging data
- Package weight
- 5.5 kg
Other features
- Output connection type
- IEC 320 C13
- Package dimensions (WxDxH)
- 190 x 291 x 257 mm
