ViewSonicInteractive Whiteboards
92inch Ultrawide Display, 21:9 Aspect Ratio, 5120 x 2160 Resolution, 500 cd/m2 high brightness
- 2.34 m (92") IPS Black
- Working area: 2141.952 x 903.636 mm
- 5120 x 2160 pixels 21:9
- 500 cd/m² 5000:1 6.5 ms
- Built-in speaker(s) 20 W Built-in subwoofer
- VESA mounting 800 x 600 mm
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
The CDE92UW is an ultrawide 92” digital display delivering stunning image performance with 5K resolution. Designed for both corporate and commercial use, it features a 21:9 aspect ratio, providing 33% more screen real estate than a comparable 16:9 display, making it ideal for Microsoft Teams Rooms and Front Row Mode. Powered by an octa-core SoC running Android 13, the CDE92UW enables seamless multitasking with a USB-C port that delivers 100W and multiple wireless content sharing options. It also supports daisy chaining and comes pre-installed with ViewSonic Manager, a centralized platform that streamlines corporate communication and enhances operational efficiency.
Specifications
Display
- Display diagonal
- 2.34 m (92")
- Display brightness
- 500 cd/m²
- Display number of colours
- 1.07 billion colours
- Display resolution
- 5120 x 2160 pixels
- Anti-glare screen
- Yes
- Panel type
- IPS
- LED backlight
- Yes
- LED backlighting type
- Direct-LED
- Native aspect ratio
- 21:9
- Contrast ratio (typical)
- 5000:1
- Response time
- 6.5 ms
- Viewing angle, horizontal
- 178°
- Viewing angle, vertical
- 178°
- Working area
- 2141.952 x 903.636 mm
- Haze rate
- 25%
- Hardness
- 3H
Computer system
- Operating system installed
- Android
- Operating system version
- 13
- Built-in processor
- Yes
- Processor architecture
- ARM Cortex A76 + ARM Cortex A55
- Processor cores
- 8
- Maximum internal memory
- 128 GB
- RAM capacity
- 8 GB
- RAM type
- DDR4
Audio
- Built-in speaker(s)
- Yes
- Number of built-in speakers
- 2
- Speaker power
- 20 W
- Built-in subwoofer
- Yes
- Subwoofer RMS power
- 2 W
Projector
- Built-in projector
- No
Ports & interfaces
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity
- 4
- HDMI ports quantity
- 4
- HDMI output ports quantity
- 1
- DisplayPorts quantity
- 1
- Line-in
- Yes
- Line-out
- Yes
- RS-232 ports
- 1
Ergonomics
- Product colour
- Black
- VESA mounting
- Yes
- Panel mounting interface
- 800 x 600 mm
Weight & dimensions
- Width
- 2182 mm
- Depth
- 85.2 mm
- Height
- 943.8 mm
- Weight
- 43.4 kg
Packaging data
- Package width
- 2360 mm
- Package depth
- 225 mm
- Package height
- 1072 mm
- Package weight
- 63 kg
- Quantity per pack
- 1 pc(s)
Packaging content
- Manual
- Yes
Logistics data
- Pallet gross width
- 2.38 m
- Pallet gross length
- 114 cm
- Pallet gross height
- 128.5 cm
- Products per master (outer) case
- 1 pc(s)
