CDEG3 Series 86“ 4K OS-Free Commercial Display

Part # CDE86G3UPC 766907035681118.6 lb

OPTIMIZED FOR VIDEOCONFERENCING: Clear 4K visuals and reliable performance for smooth, professional meetings
FAST STARTUP: Boots in seconds so meetings start on time, every time
SIMPLE CONNECTIVITY: One USB-C cable plus HDMI for quick, easy laptop connections
SEAMLESS AV INTEGRATION: Certified for Q-SYS, compatible with Crestron, Extron, and AMX
FLEXIBLE INSTALLATION: Supports portrait or landscape mounting to fit any space

Special orderPrice on request

Reply within 1 business day
Volume & business pricing
Shipping across Canada & US

Overview

The ViewSonic® CDE86G3 is a 86” commercial display designed to make meetings, trainings, and videoconferences fast, simple, and professional. Its 4K UHD resolution ensures crisp visuals for presentations and video calls, while 24/7 commercial-grade reliability keeps it running smoothly in huddle rooms, conference rooms, and executive offices. Booting in as fast as 8 seconds, the CDE86G3 gets your meetings started on time without delays. A single USB-C cable plus HDMI lets you easily connect laptops, share content, and power devices, making setup quick and effortless. Q-SYS certified and compatible with Crestron, Extron, and AMX, it integrates seamlessly into existing AV systems. With no operating system to manage, this OS-free display reduces security risks and IT complexity, giving your team a safer, low-maintenance solution. The versatile 86" size fits perfectly in a variety of meeting spaces while delivering big-screen impact.

Specifications

Display

Panel type: VA
LED backlight: Yes
LED backlighting type: Direct-LED
Display diagonal: 2.18 m (86")
Display technology: LCD
Display resolution: 3840 x 2160 pixels
Display brightness: 500 cd/m²
HD type: 4K Ultra HD
Touchscreen: No
Native aspect ratio: 16:9
Response time: 8 ms
Contrast ratio (typical): 1200:1
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 1.07 billion colours
Display diagonal (metric): 218 cm
Panel life: 50000 h
Supported video modes: 480i, 480p, 720p, 1080i, 1080p, 2160p
Colour depth: 8 bit
Native refresh rate: 60 Hz
Haze rate: 25%
Surface hardness: 3H

Ports & interfaces

HDMI ports quantity: 3
HDMI version: 2.1
HDMI input ports quantity: 3
Consumer Electronics Control (CEC): Yes
DVI port: No
VGA (D-Sub) input ports: 1
DisplayPort version: 1.2
USB port: Yes
USB ports quantity: 3
USB version: 2.0
USB connector type: USB Type-A, USB Type-C
USB Type-C DisplayPort Alternate Mode: Yes
Ethernet LAN (RJ-45) ports: 1
PC Audio in: Yes
RS-232 interface: Yes
PC Audio out: Yes
Audio Return Channel (ARC): Yes

Audio

Built-in speaker(s): Yes
Number of built-in speakers: 2
RMS rated power: 20 W

Design

Product design: Digital signage flat panel
Placement supported: Indoor
Orientation: Horizontal/Vertical
Product colour: Black
Screen shape: Flat
VESA mounting: Yes
Panel mounting interface: 600 x 400 mm
Bezel width (bottom): 1.59 cm
Bezel width (side): 1.59 cm
Bezel width (top): 1.59 cm
Anti-glare screen: Yes

Performance

Purpose: Commercial
Operating hours (hours/days): 24/7
HDCP: Yes
HDCP version: 2.2

Power

Power consumption (typical): 119.6 W
Power consumption (standby): 0.5 W
Power consumption (max): 179.2 W
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz

Computer system

Built-in processor: Yes
Processor manufacturer: MediaTek
Processor model: MTK3683

Weight & dimensions

Display width: 1933.8 mm
Display depth: 79.7 mm
Display height: 1103.8 mm
Display weight: 39.5 kg

Packaging data

Package width: 2095 mm
Package depth: 185 mm
Package height: 1220 mm
Package weight: 53.8 kg

Packaging content

Remote control included: Yes
Batteries included: Yes
Cables included: AC, HDMI
Mounting kit: Yes

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Operating altitude: 0 - 3000 m

Network

Ethernet LAN: Yes

Technical details

Sustainability certificates: ENERGY STAR, Mexico Energy
Warranty period: 3 year(s)
Compliance certificates: Federal Communications Commission (FCC), cTUVus, RoHS
