Home/Catalogue/TP-Link/TL-WR802N
Drag to turn · 7 views
N300 Pocket AP Router, 2.4GHz, 802.11n/g/b, 1 Ethernet Port, 1 Micro USB port, Internal Antenna
- 300Mbps wireless data rates is ideal for video streaming, online gaming and Internet calling*
- Pocket-size – Ideal for home and travel use
- Supports Router, Repeater, Client, AP and hotspot operation modes
- Powered through a micro USB port by an external power adapter or USB connection to a computer provides flexibility for any situation
- Easy installation in minutes
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Multiple Operating Modes
Ideal for Home and Travel Use
To meet the wireless needs of almost any situation you might encounter, the TL-WR802N supports Router, Hotspot, Range Extender, Client and Access Point Modes.
During Travel
Router Mode
Instantly create a private wireless network and share Internet access with multiple Wi-Fi devices. Ideal for setup in most hotels.
Hotspot Mode
Enjoy wireless Internet access by connecting to an outdoor WISP Access Point.
At Home
Range Extender Mode
Extend existing Wi-Fi to improve signal strength and maximize coverage.
Client Mode
Allow devices that require a wired connection to access an existing Wi-Fi network.
Access Point Mode
Create a wireless network for Wi-Fi devices.
Portable and Compact - Suitable for Home and Travel
The TL-WR802N is the smallest wireless router in the world. It is very easy to use and is a perfect choice for travelers, students, and anyone else who lives life on the go.
Flexible Power Supply - Find Power Wherever You Are
The TL-WR802N can be powered using the included power adapter or using a smartphone /USB charger.
Specifications
WAN connection
- Ethernet WAN
- Yes
- DSL WAN
- No
- SIM card slot
- No
- 3G/4G USB modem compatibility
- No
- WAN connection type
- RJ-45
Wireless LAN features
- Wi-Fi band
- Single-band (2.4 GHz)
- Top Wi-Fi standard
- Wi-Fi 4 (802.11n)
- WLAN data transfer rate (max)
- 300 Mbit/s
- Wi-Fi standards
- 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Network
- Ethernet LAN
- Yes
- Ethernet LAN interface type
- Fast Ethernet
- Ethernet LAN data rates
- 10,100 Mbit/s
- Cabling technology
- 10/100Base-T(X)
- Networking standards
- IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
- Port forwarding
- Yes
- Port triggering
- Yes
- Dynamic DNS (DDNS)
- Yes
- Number of guest networks (2.4 GHz)
- 1
- VPN Passthrough
- Yes
Ports & interfaces
- Ethernet LAN (RJ-45) ports
- 1
- USB port
- Yes
- Memory card slot(s)
- No
- DC-in jack
- Yes
Management features
- Web-based management
- Yes
- Quality of Service (QoS) support
- Yes
- Reset button
- Yes
Security
- Security algorithms
- WEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
- Firewall
- Yes
- Firewall security
- SPI
- Stateful Packet Inspection (SPI)
- Yes
- DoS attack prevention
- Yes
- Filtering
- Yes
- MAC address filtering
- Yes
- IP address filtering
- Yes
- DMZ support
- Yes
Protocols
- DHCP client
- Yes
- DHCP server
- Yes
- Universal Plug and Play (UPnP)
- Yes
- Supported network protocols
- IPv4, IPv6
Design
- Product colour
- Blue, White
- LED indicators
- Activity, LAN, Power, WLAN
- On/off switch
- Yes
- Product type
- Portable router
Certificates
- Compliance certificates
- Federal Communications Commission (FCC)
Packaging content
- Cables included
- LAN (RJ-45), USB
- AC adapter included
- Yes
- Quick installation guide
- Yes
Sustainability
- Sustainability compliance
- Yes
Antenna
- Antenna design
- Internal
- Antennas quantity
- 2
- Receive power
- 270M: -65dBm@10% PER , 130M: -70dBm@10% PER , 108M: -82dBm@10% PER , 54M: -73dBm@10% PER , 11M: -82dBm@8% PER , 6M: -86dBm@10% PER , 1M: -90dBm@8% PER
- Transmit power
- CE: , <20dBm(2.4GHz) , FCC: , <30dBm
Features
- Built-in processor
- Yes
- Processor cores
- 1
Power
- Power source type
- USB
- Output voltage
- 5 V
- Output current
- 1 A
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -40 - 70 °C
- Operating relative humidity (H-H)
- 10 - 90%
- Storage relative humidity (H-H)
- 5 - 90%
System requirements
- Windows operating systems supported
- Windows 2000, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows NT, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
- Linux operating systems supported
- Yes
- Mac operating systems supported
- macOS
Weight & dimensions
- Width
- 57 mm
- Depth
- 57 mm
- Height
- 18 mm
Packaging data
- Package width
- 110 mm
- Package depth
- 109 mm
- Package height
- 73.5 mm
- Package weight
- 240 g
Logistics data
- Harmonized System (HS) code
- 85176990
