VGA to Cat 5 Monitor Extender Kit (250ft/80m) - VGA Cat5 Extender - TAA

Part # ST121UTPEPUPC 065030835398Warranty: 2 Years0.4 lb

Extend a VGA signal to a remote display using Cat5 cabling
Works with VGA computers
Works with VGA TVs monitors and projectors
Maximum extension distance up to 250 ft. (80 m)
Supports 1920x1200 or 1600x1200 resolutions at 150 ft. (50m)
VGA extender/VGA to CAT5/CAT5 VGA extender/VGA over CAT5 extender/Remote monitor extender

Special orderPrice on request

Reply within 1 business day
Volume & business pricing
Shipping across Canada & US

Overview

Extend a VGA signal to a remote display using Cat5 cabling

The ST121UTPEP VGA Video Extender over Cat5 - Point to Point lets you connect a remote VGA display/projector up to 80m (250ft) away from the VGA signal source. The ST121UTPEP is a bundled kit that includes both a local and a remote unit providing a complete end to end solution for a single source/display connection, transmitting the source VGA signal over a standard Ethernet cable (Cat5 or better UTP cable, terminated with RJ45 connectors).

Offering convenient and cost-effective VGA distribution, the ST121UTPEP only requires one power adapter which can be installed at either the local or remote end of the connection, depending on what is most convenient for your application.

To ensure a tidy installation, the ST121UTPEP includes a mounting bracket for the receiver to help eliminate unnecessary cable tangles.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Specifications

Features

Type: AV transmitter & receiver
Maximum resolution: 1920 x 1200 pixels
Cable types supported: Cat5
Maximum transfer distance: 80 m
Supported graphics resolutions: 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
Material: Aluminium
Plug and Play: Yes
Daisy chain: No
Product colour: Black
Certification: CE, FCC, REACH, TAA

Ports & interfaces

RJ-45 input ports: 1
RJ-45 output ports: 1
VGA (D-Sub) input ports: 1
VGA (D-Sub) output ports: 1
DC-in jack: Yes

Power

Operating voltage: 12 V
Output current: 0.6 A
Power consumption (typical): 7.2 W
External power adapter: Yes
Power plug type: Type M

Weight & dimensions

Width: 138 mm
Depth: 100 mm
Height: 25 mm
Weight: 263 g

Packaging data

Package width: 144 mm
Package depth: 316 mm
Package height: 62 mm
Package weight: 795 g

Packaging content

AC adapter included: Yes
Cables included: VGA
Included power plug types: AU, EU, NA, UK
Manual: Yes
Mounting brackets included: Yes

Technical details

Compliance certificates: RoHS

Logistics data

Master (outer) case width: 332 mm
Master (outer) case length: 336 mm
Master (outer) case height: 318 mm
Products per master (outer) case: 10 pc(s)
