1-Port Parallel PCIe Card - PCI Express to Parallel DB25 Adapter Card - Desktop Expansion LPT
- Parallel PCIe card | Add a DB25 parallel port using a PCI Express 2.0 Gen 1 full or low profile PCIe x1 card slot (brackets incl) | Full profile bracket installed | Latest version of our popular PEX1P parallel card
- TECH SPECS: SPP/Byte/Nibble/ECP modes | Compatible w/IEEE 1284 up to 2.5Mbps | Asix AX99100 chip
- Use parallel port LPT controller with printers/scanners/plotters
- Parallel port expansion/adapter card is compliant with PCI-e Base Spec. Rev 1.1/PCI Power Mgmt 1.2
- Windows/Linux
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
PCI Express 2.0 | LPT | PCIe 1x Slot | 2.5 Mbps | 2-Year Warranty
This PCIe Parallel controller card installs into an available PCI-Express x1 slot in your computer and enables you to add DB25 parallel communication port to your system.
Adds a Parallel Port to Your Desktop Computer
The controller card features an Asix AX99100 chip and enables you to connect a DB25 device to your desktop computer. The parallel port port is ideal for connecting printers, scanners, plotters, point-of-sale terminals, PLCs, scientific sensors, medical equipment or oscilloscopes. The card can also be used in factories, to control or automate equipment. The parallel (LPT) port supports SPP/Byte/Nibble/ECP modes and is compatible with PCI Power Management 1.2 and IEEE 1284 for speeds up to 2.5Mbps.
Wide Installation Compatibility
This add-on card includes both full-profile and low-profile installation brackets (full-profile bracket pre-installed) ensuring you can install it into either a full or low-profile PCIe 2.0 x1 slot (backward compatible with PCIe 1.1). For wide platform support the card is compatible with Windows (XP or higher), Windows Server (2003 or higher), and Linux (2.6.X or higher).
PEX1P2 is backed by a StarTech.com 2-year warranty with free 24/5 multi-lingual North American based technical support. StarTech.com has been the IT professionals' choice for over 30 years.
Specifications
Ports & interfaces
- Host interface
- PCIe
- Output interface
- Parallel
- Expansion card standard
- PCIe 1.0a
- Parallel ports quantity
- 1
Design
- Internal
- Yes
- Product colour
- Black, Steel
- Mean time between failures (MTBF)
- 26297 h
Features
- Chipset
- PLX/Oxford - OXPCIe952
System requirements
- Windows operating systems supported
- Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
- Linux operating systems supported
- Yes
- Server operating systems supported
- Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Technical details
- Compliance certificates
- CE, RoHS
Weight & dimensions
- Width
- 110 mm
- Depth
- 210 mm
- Height
- 120 mm
- Weight
- 42 g
Packaging data
- Mounting brackets included
- Yes
- Drivers included
- Yes
- Manual
- Yes
- Package width
- 216 mm
- Package depth
- 146 mm
- Package height
- 37 mm
- Package weight
- 133 g
Logistics data
- Harmonized System (HS) code
- 84733020
- Products per master (outer) case
- 40 pc(s)
- Master (outer) case width
- 450 mm
- Master (outer) case length
- 379 mm
- Master (outer) case height
- 327 mm
Other features
- Data transfer rate
- 2.5 Mbit/s
- Material
- Steel
