HDMI to VGA Adapter, Active Video Converter For Laptop/Desktop, 1920x1080 (1080p), HDMI Source to
- HDMI to VGA Adapter converts from an HDMI video source to a VGA output for connecting legacy monitors/displays
- Supports up to 1920x1200/1920x1080 (1080p)
- Universal Video Converter is compatible with any OS
- Works with HDMI laptops/desktops/Chromebooks from all hardware platforms (Intel/ Nvidia/AMD)
- No power adapter or USB power connection required reduces clutter and simplifies the setup
- Connect a VGA monitor or projector or add a secondary extended/mirrored display to a workstation
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Connect an HDMI-enabled laptop or desktop to a VGA display or projector
This active HDMI to VGA adapter converts an HDMI video source to a VGA output, allowing connection to legacy VGA monitors, displays, and projectors.
No Drivers or Software
This universal video converter requires no drivers or software and is compatible with any operating system, including Windows, macOS, ChromeOS, and Linux. It works with HDMI-enabled laptops, desktops, tablets, and Chromebooks from all hardware platforms, such as Intel, Nvidia, and AMD. It supports resolutions up to 1920x1200 or 1920x1080 at 60Hz, utilizing the integrated or dedicated GPU for minimal CPU usage.
No External Power Required
The adapter reduces clutter and simplifies setup by eliminating the need for an external power adapter or USB power connection. The Adapter has a compact and lightweight design, making it ideal for travel or on-the-go use. This black video adapter features a 5mm cable outer diameter, and a cable length of 5.8 inches (14.7 cm).
Connect a Primary or Secondary Display
Connect a primary VGA monitor to the host, or add a secondary extended or mirrored display to a workstation. It supports VGA screw-locking cables to prevent the cable from coming loose or accidentally disconnecting.
Note: This video adapter is unidirectional, converting only from an HDMI source to a VGA monitor or display.
Specifications
Features
- Converter type
- Active video converter
- Internal
- No
- Plug and Play
- Yes
- Housing material
- Plastic
- Cable length
- 0.189 m
Video
- Maximum video resolution
- 1920 x 1200 pixels
- Video resolutions
- 800 x 600,1024 x 768,1280 x 720,1280 x 800,1600 x 1200,1680 x 1050,1920 x 1080,1920 x 1200
- Supported video modes
- 1080p
- Colour depth
- 8 bit
- Maximum refresh rate
- 75 Hz
Ports & interfaces
- Host interface
- HDMI
- Output interface
- VGA
Power
- External power adapter
- No
Technical details
- Compliance certificates
- RoHS
Operational conditions
- Operating temperature (T-T)
- 0 - 70 °C
- Storage temperature (T-T)
- -10 - 80 °C
- Operating relative humidity (H-H)
- 0 - 75%
Weight & dimensions
- Width
- 45 mm
- Depth
- 234 mm
- Height
- 15 mm
- Weight
- 33 g
Packaging data
- Package width
- 126 mm
- Package depth
- 138 mm
- Package height
- 20 mm
- Package weight
- 53 g
Other features
- Chipset
- AG6203
Logistics data
- Master (outer) case width
- 400 mm
- Master (outer) case length
- 440 mm
- Master (outer) case height
- 292 mm
- Products per master (outer) case
- 200 pc(s)
