1-Port 10Gbps PoE++ Injector, 60W, 2.5/5/10G Ethernet/10/100/1000M, PoE++ (802.3af/at/bt), Wall

Part # AF31XC-POE-INJECTORUPC 065030905794Warranty: 2 Years1.05 lb

Single port unmanaged PoE++ injector supports up to 2.5/5/10G Ethernet and 10/100/1000Mbps
Up to 60 Watts PoE/PoE+/PoE++ (802.3af/at/bt) output to a remote Powered Device (PD)
Extend power and Gigabit data at distances of up to 100m
Features network multi-speed auto-negotiation
Surge protection up to 2Kv
No software or drivers required

Special orderPrice on request

Reply within 1 business day
Volume & business pricing
Shipping across Canada & US

Overview

Supply power and data to a PoE device over standard Ethernet cabling

This 1-Port multi-speed PoE++ Injector serves as a Power Sourcing Equipment (PSE) device and enables Ethernet speeds of 10/100 Mbps/1000Mbps and 1/2.5/5/10Gbps. This TAA-compliant mid-span inline injector can transmit network data and power up to 328ft (100m) for single Powered Devices (PD).

Versatile PoE Injector

Single port PoE+ injector supports the IEEE 802.3af and 802.3at PSE standards, and delivers up to 60W output (54V, 1.11A). Connect a remote PoE device to a network at a location where there is no power source, but an Ethernet cable already exists. This includes access points, IP cameras, VoIP phone systems, IPTV and access controls. The flexible design of the PoE injector allows for either desktop or surface-mount use.

Streamlined Cable Management

All Ethernet cables can be routed from one side of the unit for efficient and organized cable management. The compact design (4x2.3x1.3-inch / 100x58.4x33.4mm) ensures straightforward integration into existing network infrastructure, saving space and time during installation.

Specifications

Network

Ethernet interface type: 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet LAN data rates: 10,100,1000,2500,5000,10000 Mbit/s
Cabling technology: 1000/10000
Power over Ethernet (PoE): Yes
Networking standards: IEEE 802.3ab, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3u
Auto MDI/MDI-X: Yes
Web-based management: No
Chipset: SkyWorks - Si3471A-A01
