Samsung LH13QBCEBGBXZA Drag to turn · 7 views
SamsungSignage Displays

13.3 FHD, w/MagicInfo S6 Player, Tizen 4.0, IP5x, 16/7, 300nit, Edge LED, HDMI 1.4, HDCP 2.2, 5W x

Part # LH13QBCEBGBXZAUPC 1989571054633.55 lb

  • Compact 13" Size & Slim Design
  • Home UI
  • Dual Wi-Fi (2.4GHz + 5GHz)
Special orderPrice on request
View quote list
  • Reply within 1 business day
  • Volume & business pricing
  • Shipping across Canada & US

Overview

Effective display for compact places

The newly refined QB13C delivers a slim, space-efficient design with a 13-inch display that integrates seamlessly into diverse business settings. Its intuitive usability, reliable performance and easy management brings the essentials of business signage into compact spaces.

Smaller and slimmer, greater flexibility

01

Compact 13" Size & Slim Design

Slimmer than ever at 19.9mm, the 13-inch compact display fits flawlessly in tight spaces, perfect for maximizing visibility without hindering performance. Its smaller design packs the same reliable performance businesses demand, making it a smart choice for any space.

Intuitive accessibility meets effortless usability

02

Home UI

The QB13C features Home UI upgrades for faster, more intuitive control. Key tools such as Features, Sources, and settings are grouped for quicker access, while the Favorites folder brings you to frequently used tools in one click.

Faster, smoother wireless performance

03

Dual Wi-Fi (2.4GHz + 5GHz)

QB13C now supports dual-band Wi-Fi with both 2.4GHz and 5GHz frequencies, enabling faster network connections and higher data transmission speeds—especially in high-traffic areas.

Empower your business with smart control

04

SmartThings Pro

Samsung SmartThings now extends beyond the home with SmartThings Pro for business environments. Businesses, from small shops to large companies and hotels, can experience enhanced convenience, safety, and energy efficiency with SmartThings Pro connectivity.

Change the way to manage your display

05

Samsung VXT

Samsung VXT is a cloud-based solution that brings together content management and remote device management capabilities, allowing users to remotely manage hardware settings and troubleshoot issues from afar, while effortlessly creating and deploying content without the need for training.

Specifications

Display

Panel type
ADS
Display diagonal
33 cm (13")
Display technology
LED
Display resolution
1920 x 1080 pixels
Display brightness
500 cd/m²
HD type
Full HD
Touchscreen
No
Response time
30 ms
Contrast ratio (typical)
800:1
Contrast ratio (dynamic)
10000:1
Viewing angle, horizontal
178°
Viewing angle, vertical
178°
Pixel pitch
0.153 x 0.153 mm
Colour saturation
45%
Horizontal scan range
56 - 84.5 kHz
Vertical scan range
48 - 75 Hz
Pixel frequency (max)
148.5 MHz

Ports & interfaces

HDMI ports quantity
1
HDMI version
1.4
USB port
Yes
USB ports quantity
1
Ethernet LAN (RJ-45) ports
1
RS-232 interface
Yes
PC Audio out
Yes

Design

Product design
Digital A-board
Placement supported
Indoor
Product colour
Black
Screen shape
Flat
VESA mounting
Yes

Performance

Purpose
Universal
Operating hours (hours/days)
16/7

Power

Power consumption (typical)
35 W
Power consumption (standby)
0.5 W
AC input voltage
100-240 V
AC input frequency
50/60 Hz

Computer system

Operating system installed
Android
Operating system version
Tizen 7.0

Weight & dimensions

Display width
322 mm
Display depth
19.9 mm
Display height
193.5 mm
Display weight
800 g

Packaging data

Package width
520 mm
Package depth
238 mm
Package height
64 mm
Package weight
1.6 kg

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 80%

Network

Ethernet LAN
Yes
Wi-Fi
Yes
