SamsungSignage Displays
QHC Series 115 UHD, 1,000nit, Non glare, IP5x rated, 24/7, 2nd Gen B2B Design, Tizen 8.0, MagicInfo
- Indoor Digital signage flat panel Black
- 2.92 m (115") 3840 x 2160 pixels LED 1000 cd/m²
- 120 Hz 6.5 ms
- Ethernet LAN Wi-Fi
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
QHC Series 115 UHD, 1,000nit, Non glare, IP5x rated, 24/7, 2nd Gen B2B Design, Tizen 8.0, MagicInfo S10 Player, SSSP 10.0, Pixel Pitch 0.630 x 0.630 mm, Ambient SensorDP 1.4 1x, HDMI 2.1 3x, HDCP 2.2, USB 2.0 2x, Wifi 2.4/5.0 GHz dual, Bluetooth, 16GB Internal Storage, RS232C In Out, RJ45 In, SmartView+, 2 Speakers 10W
Specifications
Display
- Panel type
- VA
- Display diagonal
- 2.92 m (115")
- Display technology
- LED
- Display resolution
- 3840 x 2160 pixels
- Display brightness
- 1000 cd/m²
- HD type
- 4K Ultra HD
- Touchscreen
- No
- Native aspect ratio
- 16:9
- Response time
- 6.5 ms
- Contrast ratio (typical)
- 5500:1
- Dynamic contrast ratio marketing name
- Mega Contrast
- Viewing angle, horizontal
- 178°
- Viewing angle, vertical
- 178°
- Pixel pitch
- 0.63 x 0.63 mm
- Horizontal scan range
- 15 - 135 kHz
- Vertical scan range
- 24 - 120 Hz
- Native refresh rate
- 120 Hz
- Haze rate
- 25%
Ports & interfaces
- HDMI ports quantity
- 3
- HDMI version
- 2.1
- DisplayPorts quantity
- 1
- DisplayPort version
- 1.4
- USB port
- Yes
- USB connector type
- USB Type-A
- Ethernet LAN (RJ-45) ports
- 1
- RS-232 interface
- Yes
- PC Audio out
- Yes
Design
- Product design
- Digital signage flat panel
- Placement supported
- Indoor
- Orientation
- Horizontal/Vertical
- Product colour
- Black
- Screen shape
- Flat
- VESA mounting
- Yes
- Panel mounting interface
- 1000 x 600 mm
- Bezel type
- 3 Bezel-less
Performance
- Purpose
- Universal
- Operating hours (hours/days)
- 24/7
- HDCP
- Yes
- HDCP version
- 2.2
Power
- Power consumption (typical)
- 836 W
- Power consumption (standby)
- 0.5 W
- Power consumption (sleep)
- 0.5 W
- Energy efficiency class (SDR)
- G
- Energy efficiency class (HDR)
- G
- AC input voltage
- 100-240 V
- AC input frequency
- 50/60 Hz
Computer system
- Internal storage capacity
- 16 GB
- Operating system installed
- Tizen
- Operating system version
- Tizen 8.0
Weight & dimensions
- Display width
- 2565.2 mm
- Display depth
- 34.1 mm
- Display height
- 1467.6 mm
- Display weight
- 83.7 kg
Packaging data
- Package width
- 2765 mm
- Package depth
- 250 mm
- Package height
- 1652 mm
- Package weight
- 133.6 kg
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- 20 - 95 °C
Network
- Ethernet LAN
- Yes
- Wi-Fi
- Yes
Other features
- Power supply type
- Internal
Downloads
