LGSignage Displays
UHD IPS Display, BrightSignOS 6.0, 500 nits brightness, 3840x2160 resolution, 60Hz Refresh rate
- Resolution: 3,840 × 2,160 (UHD)
- Brightness: 500 nit (Typ.)
- 8.9 mm (T/R/L), 12.9 mm (B)
- BrightSignOS
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
UHD IPS Display, BrightSignOS 6.0, 500 nits brightness, 3840x2160 resolution, 60Hz Refresh rate, 178x178 viewing angle, 16GB Internal Memory (eMMC), Auto brightness sensor, 120:1 Contrast ratio, Screen rotation, Gapless playback, Screen rotation, ISM method, Smart energy saving, Pro:Idiom, Auto set ID, PM Mode, Screen share,
Specifications
Display
- Panel type
- IPS
- LED backlight
- Yes
- LED backlighting type
- Edge-LED
- Display diagonal
- 165.1 cm (65")
- Display resolution
- 3840 x 2160 pixels
- Display brightness
- 500 cd/m²
- HD type
- 4K Ultra HD
- Touchscreen
- No
- Native aspect ratio
- 16:9
- Contrast ratio (typical)
- 1100:1
- Contrast ratio (dynamic)
- 1000000:1
- Viewing angle, horizontal
- 178°
- Viewing angle, vertical
- 178°
- Display number of colours
- 1.07 billion colours
- Number of displays
- 1
- Panel life
- 50000 h
- Native refresh rate
- 60 Hz
- Touch response time
- 10 ms
Ports & interfaces
- HDMI ports quantity
- 4
- HDMI input ports quantity
- 3
- HDMI output ports quantity
- 1
- DisplayPorts quantity
- 1
- USB port
- Yes
- USB 2.0 Type-B ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 1
- RS-232C
- Yes
- Remote (IR) input
- 1
Audio
- Built-in speaker(s)
- Yes
- Number of built-in speakers
- 2
- RMS rated power
- 20 W
Design
- Product design
- Digital signage flat panel
- Placement supported
- Indoor
- Orientation
- Horizontal/Vertical
- Product colour
- Black
- Screen shape
- Flat
- VESA mounting
- Yes
- Panel mounting interface
- 300 x 300 mm
- Bezel width (bottom)
- 1.29 cm
- Bezel width (side)
- 8.9 mm
- Bezel width (top)
- 8.9 mm
Performance
- On Screen Display (OSD)
- Yes
- Operating hours (hours/days)
- 24/7
- HDCP
- Yes
- HDCP version
- 1.4/2.2
Power
- Power consumption (typical)
- 145 W
- Power consumption (standby)
- 0.5 W
- Power consumption (off)
- 0.5 W
- Power consumption (max)
- 200 W
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50/60 Hz
- Heat generation (typical)
- 495 BTU/h
- Heat generation (max)
- 682 BTU/h
Computer system
- Internal memory
- 16 GB
- Operating system installed
- WebOS
- Operating system version
- 6.0
Weight & dimensions
- Display width
- 1450.3 mm
- Display depth
- 29.7 mm
- Display height
- 830.3 mm
- Display weight
- 24.2 kg
Packaging data
- Package width
- 1600 mm
- Package depth
- 172 mm
- Package height
- 970 mm
- Package weight
- 30.4 kg
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 10 - 80%
Network
- Ethernet LAN
- Yes
- Wi-Fi
- Yes
Downloads
