Drag to turn · 7 views
VA, Direct LED, 16:9 Aspect Ratio, 60Hz Refresh Rate, 4,000:1 Contrast Ratio, 178 x 178 Viewing
- Brightness : 390 nit (w/o Glass, Typ.)
- Multi Touch Point : 20 Points (Max.)
- Interface : HDMI, RGB, Audio In, RS-232C In, RJ45, USB 3.0 Type A, USB 2.0 Type A, USB Type-C, Audio Out / Optical Output, Touch USB
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
True Interactivity for Bringing People Together
Multi Touch
The TR3DJ series can simultaneously use up to 20 points of multi touch. This function offers a lifelike board touch experience and makes collaboration much easier.
Enhanced Visibility with Low Parallax
With 1mm gap between the screen and tempered glass, which supports low parallax, The TR3DJ series can offer precise touch and excellent writing experience.
Dual Pen & Dual Color
The stylus pen comes in two different colors and with two different tip sizes of 3mm and 8mm. The dual pens enable users to write or draw simultaneously.
Easy Writing Experience
The TR3DJ series allows you to write and annotate on sources, so your writing experience can be easy and satisfying.
Air Class
Air Class supports connecting up to 30 students and offers interactive meetings for mobile devices on the same network, providing a variety of tools such as voting, answering, and sharing project texts. Air Class is easily accessible from the TR3DJ's main toolbar.
Built-in OPS Slot
The TR3DJ series supports OPS* slots, allowing you to easily and conveniently mount an OPS* device at the back of the digital board without the hassle of connecting to an external desktop, offering you more expanded functions.
ScreenShare Pro
ScreenShare Pro enables you to show up to six shared screens or a file on a screen in real-time, and it has enhanced usability by allowing users to share Chromecast and Apple device mirroring on the same network without any additional application.
Bluetooth Connectivity
TR3DJ supports Bluetooth wireless connections to various devices such as speaker, mouse, keyboard, etc. This is optimal for building a hybrid environment so that online and offline meetings and classes can proceed smoothly
Web Browser
The TR3DJ series supports an embedded Android web browser, so you can search the web easily and quickly, without connecting to an external tablet or computer.
Toolbar
The Toolbar allows you to easily find and run the tool you need. The annotation feature works on virtually all file types, and you can highlight the section you wish to emphasize using the Spotlight function. The countdown and stopwatch features help you manage class time effectively.
Audio Experience
The TR3DJ series supports built-in speakers in both sides of the front bezel which deliver clear audio experience.
USB Block
USB Block Mode is a security measure that helps prevent data from being copied to unauthorized devices, which is essential for being used in spaces where security is critical.
Specifications
Display
- LED backlighting type
- Direct-LED
- Display diagonal
- 165.1 cm (65")
- Display technology
- LED
- Display resolution
- 3840 x 2160 pixels
- Display brightness
- 390 cd/m²
- HD type
- 4K Ultra HD
- Touchscreen
- Yes
- Touchscreen technology
- Infrared
- Number of simultaneous touchpoints
- 20
- Multi-touch
- Yes
- Native aspect ratio
- 16:9
- Response time
- 6.5 ms
- Contrast ratio (typical)
- 4000:1
- Viewing angle, horizontal
- 178°
- Viewing angle, vertical
- 178°
- Display number of colours
- 1.07 billion colours
- Rated lifetime
- 30000 h
- Native refresh rate
- 60 Hz
- Haze rate
- 25%
- Surface hardness
- 7H
- RGB colour space
- NTSC
Ports & interfaces
- HDMI ports quantity
- 4
- HDMI input ports quantity
- 3
- HDMI output ports quantity
- 1
- DVI port
- No
- USB port
- Yes
- USB version
- 2.0/3.2 Gen 1 (3.1 Gen 1)
- USB connector type
- USB Type-A, USB Type-B, USB Type-C
- PC Audio in
- Yes
- RS-232C
- Yes
- Infrared data port
- Yes
- Remote (IR) input
- 1
- PC Audio out
- Yes
- OPS module slot
- Yes
Audio
- Built-in speaker(s)
- Yes
- Number of built-in speakers
- 2
- RMS rated power
- 24 W
Design
- Product design
- Digital signage flat panel
- Placement supported
- Indoor
- Orientation
- Horizontal
- Product colour
- Black
- Screen shape
- Flat
- VESA mounting
- Yes
- Panel mounting interface
- 600 x 400 mm
- Bezel width (bottom)
- 4.57 cm
- Bezel width (side)
- 1.77 cm
- Bezel width (top)
- 1.77 cm
- Anti-glare screen
- Yes
Performance
- Purpose
- Education
- On Screen Display (OSD)
- Yes
- Operating hours (hours/days)
- 16/7
- HDCP
- Yes
- HDCP version
- 1.4/2.2
- Open Pluggable Specification (OPS)
- Yes
Power
- Power consumption (typical)
- 180 W
- Power consumption (off)
- 0.5 W
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50 - 60 Hz
- Heat dissipation
- 955 BTU/h
Computer system
- Computer system
- Yes
- Built-in processor
- Yes
- Processor architecture
- ARM Cortex-A73
- Processor cores
- 4
- On-board graphics card model
- ARM Mali-G51
- Internal storage capacity
- 32 GB
- Operating system installed
- Android 9.0
Weight & dimensions
- Display width
- 1489 mm
- Display depth
- 87 mm
- Display height
- 897 mm
- Display weight
- 40.2 kg
Packaging data
- Package width
- 1628 mm
- Package depth
- 208 mm
- Package height
- 1005 mm
- Package weight
- 48.8 kg
Packaging content
- Remote control included
- Yes
- Batteries included
- Yes
- Stylus pen
- Yes
- Number of stylus pens
- 2
- Cables included
- AC, HDMI, USB Type-A to USB Type-B
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 10 - 80%
Network
- Ethernet LAN
- Yes
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Wi-Fi
- Yes
- Wi-Fi standards
- Wi-Fi 5 (802.11ac)
Other features
- Bluetooth
- Yes
- Bluetooth version
- 5.0
