LGSignage Displays
IPS, Direct LED, 16:9 Aspect Ratio, 60Hz Refresh Rate, 1,000:1 Contrast Ratio, 178 x 178 Viewing
- Brightness(Typ.) : 500 nit
- Bezel : 2.25 mm (T/L), 1.25 mm (B/R)
- Depth : 89.7 mm
- Interface : HDMI/ DP/ DVI-D/ USB/ RS232C/ RJ45/ Audio/ IR
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Daisy Chain Capability
By using this daisy-chained network feature, you can execute commands such as controlling, monitoring and even updating firmware.
01
Real-Time LG ConnectedCare
Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, enabling the stable operation of clients' businesses.
Specifications
Display
- Panel type
- IPS
- LED backlighting type
- Direct-LED
- Display diagonal
- 124.5 cm (49")
- Display resolution
- 1920 x 1080 pixels
- Display brightness
- 500 cd/m²
- HD type
- Full HD
- Touchscreen
- No
- Native aspect ratio
- 16:9
- Response time
- 8 ms
- Contrast ratio (typical)
- 1000:1
- Contrast ratio (dynamic)
- 500000:1
- Viewing angle, horizontal
- 178°
- Viewing angle, vertical
- 178°
- Display number of colours
- 1.07 billion colours
- Rated lifetime
- 60000 h
- Native refresh rate
- 60 Hz
- Haze rate
- 3%
Ports & interfaces
- HDMI ports quantity
- 2
- HDMI version
- 2.2
- DVI port
- Yes
- DVI-D ports quantity
- 1
- DisplayPorts quantity
- 1
- USB port
- Yes
- USB ports quantity
- 1
- USB version
- 2.0
- Ethernet LAN (RJ-45) ports
- 1
- RS-232C
- Yes
Design
- Product design
- Panorama design
- Product colour
- Black
- Screen shape
- Flat
- VESA mounting
- Yes
- Panel mounting interface
- 600 x 400 mm
- Bezel width (bottom)
- 2.25 mm
- Bezel width (side)
- 1.25 mm
- Bezel width (top)
- 2.25 mm
Performance
- Purpose
- Commercial
- On Screen Display (OSD)
- Yes
- Operating hours (hours/days)
- 24/7
Power
- Power consumption (typical)
- 110 W
- Power consumption (off)
- 0.5 W
- Energy efficiency class (SDR)
- G
- Energy consumption (SDR) per 1000 hours
- 73 kWh
- AC input voltage
- 100-240 V
- AC input frequency
- 50 - 60 Hz
- Heat dissipation
- 375 BTU/h
- Energy efficiency scale
- A to G
Weight & dimensions
- Display width
- 1077.6 mm
- Display depth
- 89.7 mm
- Display height
- 607.8 mm
- Display weight
- 17.8 kg
Packaging data
- Package width
- 1198 mm
- Package depth
- 247 mm
- Package height
- 756 mm
- Package weight
- 21.9 kg
Packaging content
- Remote control included
- Yes
- Cables included
- DisplayPort, LAN (RJ-45), Power
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 10 - 80%
Network
- Ethernet LAN
- Yes
- Wi-Fi
- No
Downloads
