Home/Catalogue/Lenovo/30KB001HUS
Drag to turn · 11 views
ThinkStation P5 Gen 2 Intel® Xeon® 638 64 GB DDR5-SDRAM 2 TB SSD Windows 10 Pro for Workstations Workstation
- Intel Xeon 638, 16C (16P + 0E)/32T, 3.2/4.8GHz, 72MB
- 4x 16GB RDIMM DDR5-6400 ECC
- 1x 2TB SSD M.2 2280 PCIe 5.0x4 NVMe Opal
- 1x NVIDIA RTX PRO 2000 Blackwell 16GB GDDR7
- Windows 11 Pro for Workstations
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
THE INDUSTRY WORKHORSE
A Future-Ready Workstation With Engineering Excellence
The Lenovo ThinkStation P5 Gen 2 tower is a modular workstation built to accelerate modern workflows. Powered by Intel® Xeon® 600 processors and NVIDIA RTX PRO™ Blackwell GPUs, it delivers AI-ready performance and real-time visualization, handling compute-intensive tasks with utmost precision. Ideal for designers, engineers, and creatives alike.
MODULAR DESIGN
Tool-Free Design, Non-Stop Performance
The P5 Gen 2 tower’s tool-free, modular chassis and front-access, hot-swap storage make hardware upgrades fast, easy and smooth — without shutting down active workflows. Stay consistently productive while seamlessly adapting to evolving project demands.
ENTERPRISE-CLASS SECURITY
Comprehensive Data-Device Protection
For mission-critical and enterprise environments, layered protection isn't optional — it's essential. ThinkShield security offers end-to-end encryption while hardware-based Intel® protections prevent unauthorized access. BIOS and firmware safeguards play a crucial role in secure boot processes, maintaining system integrity and ensuring peace of mind.
ROBUST THERMAL MANAGEMENT
Built to Run Hard & Stay Cool
Enjoy uninterrupted system performance on the P5 Gen 2 workstation. Its unique air baffle design, large 3D hex ventilation openings, and Lenovo's patented tri-channel cooling system efficiently manages heat across CPUs and GPUs. Long renders, complex simulations, and intensive AI workloads won't slow it down or make it louder than it needs to be.
CREDIBILITY & COLLABORATION
Sustainability
Our goal is to provide smarter technology that builds a brighter, more sustainable future for our customers, communities, and the planet. That's why we pursue industry leading labels and certifications that demonstrate our commitment to sustainability in product design. Together, we can build a smarter future for all.
Specifications
Processor
- Processor manufacturer
- Intel
- Processor family
- Intel® Xeon®
- Processor model
- 638
- Processor cores
- 16
- Processor threads
- 32
- Processor boost frequency
- 4.8 GHz
- Processor frequency
- 3.2 GHz
- Processor cache
- 72 MB
Memory
- Internal memory
- 64 GB
- Maximum internal memory
- 1 TB
- Internal memory type
- DDR5-SDRAM
- Memory layout (slots x size)
- 4 x 16 GB
- Memory slots
- 8x DIMM
- Memory clock speed
- 6400 MHz
Storage
- Total storage capacity
- 2 TB
- Storage media
- SSD
- Optical drive type
- No
- Total SSDs capacity
- 2 TB
- Number of SSDs installed
- 1
- SSD capacity
- 2 TB
- SSD interface
- PCI Express 5.0
- NVMe
- Yes
- SSD form factor
- M.2
- M.2 SSD size
- 2280 (22 x 80 mm)
- Self-Encrypting Drive (SED)
- Yes
Graphics
- Discrete graphics card
- Yes
- Discrete graphics card memory
- 16 GB
- Discrete graphics memory type
- GDDR7
- Number of discrete graphics cards
- 1
Performance
- Motherboard chipset
- Intel W890
- Trusted Platform Module (TPM)
- Yes
- Product type
- Workstation
Network
- Ethernet LAN
- Yes
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Wi-Fi
- Yes
- Top Wi-Fi standard
- Wi-Fi 7 (802.11be)
- Wi-Fi standards
- Wi-Fi 7 (802.11be)
- WLAN controller manufacturer
- Intel
- Antenna type
- 2x2
- Bluetooth
- Yes
- Bluetooth version
- 5.4
Ports & interfaces
- USB 2.0 ports quantity
- 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 3
- USB 3.2 Gen 2x2 Type-C ports quantity
- 1
- Ethernet LAN (RJ-45) ports
- 1
- Combo headphone/mic port
- Yes
- Line-out
- Yes
- Line-in
- Yes
Power
- Power supply
- 1000 W
Design
- Cable lock slot
- Yes
- Cable lock slot type
- Kensington
Software
- Operating system installed
- Windows 10 Pro for Workstations
- Bundled software
- Lenovo AI Now
Audio
- Audio chip
- Realtek ALC897
- Audio system
- High Definition Audio
Weight & dimensions
- Width
- 165 mm
- Depth
- 453.9 mm
- Height
- 440 mm
- Weight
- 19 kg
Packaging content
- Mouse included
- Yes
- Mouse connectivity
- Wired
- Keyboard included
- Yes
Keyboard
- Keyboard connectivity
- Wired
Downloads
