ThinkBook 14x ILL Copilot+ PC Intel Core Ultra 5 226V Laptop 35.6 cm (14") WUXGA 16 GB
- Intel Core Ultra 5 226V, 8C (4P + 4LPE)/8T, Max Turbo up to 4.5GHz, 8MB Intel Smart Cache
- 14" WUXGA (1920x1200) IPS 400nits 100% sRGB 120Hz
- 16GB LPDDR5X-8533, MoP Memory
- 256GB SSD M.2 2242 PCIe 4.0x4 NVMe
- Intel Arc Graphics 130V
- Windows 11 Pro
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Thin, Light & Reimagined for Mobile Productivity
Thin and light, this Copilot+ PC is crafted with sleek metallic exteriors and a uniquely engineered bottom cover design. By concentrating critical components and I/O into a small section, the device stays slim. Enjoy a remarkably portable laptop that feels premium and looks distinct – including special editions in Mystic Violet and Veil Blue.
AI-Ready Performance Powered by Intel® Core™ Ultra and Intel® Arc™
Powered by the Intel® Core™ Ultra processor family, up to Intel® Core™ Ultra 7 258V, with Intel® Arc™ graphics, this device delivers responsive everyday performance with smarter AI readiness. It is built to handle multitasking, content creation, presentations, and visually rich work with greater speed and efficiency.
Smart Connect, for Seamless Cross-Device Accessibility
Access and work across devices more easily with Lenovo Smart Connect. With a dedicated keyboard key for quick access, users can connect their PC and phone for a smoother, more unified experience – making content, communication, and everyday tasks easier to manage across screens.
CREDIBILITY & COLLABORATION
Sustainability
Our goal is to provide smarter technology that builds a brighter, more sustainable future for our customers, communities, and the planet. That's why we pursue industry-leading labels and certifications that demonstrate our commitment to sustainability in product design. Together, we can build a smarter future for all.
Specifications may vary depending upon region / model.
Specifications
Design
- Colour name
- Luna Grey
- Product type
- Laptop
- Product colour
- Grey
- Form factor
- Clamshell
- Housing material
- Aluminium
- Display back cover material
- Aluminium
Display
- Display diagonal
- 35.6 cm (14")
- Display resolution
- 1920 x 1200 pixels
- Touchscreen
- No
- HD type
- WUXGA
- Panel type
- IPS
- LED backlight
- Yes
- Native aspect ratio
- 16:10
- Anti-glare screen
- Yes
- Display brightness
- 400 cd/m²
- RGB colour space
- sRGB
- Colour gamut
- 100%
- Maximum refresh rate
- 120 Hz
Processor
- Processor manufacturer
- Intel
- Processor family
- Intel Core Ultra 5
- Processor model
- 226V
- Processor cores
- 8
- Processor threads
- 8
- Processor cache
- 8 MB
- Processor cache type
- Smart Cache
Neural processor unit (NPU)
- Copilot+ PC
- Yes
Memory
- Internal memory
- 16 GB
- Internal memory type
- LPDDR5x-SDRAM
- Memory clock speed
- 8533 MHz
- Memory form factor
- On-board
- Maximum internal memory
- 16 GB
Storage
- Total storage capacity
- 256 GB
- Storage media
- SSD
- Total SSDs capacity
- 256 GB
- Number of SSDs installed
- 1
- SSD capacity
- 256 GB
- SSD interface
- PCI Express 4.0
- NVMe
- Yes
- SSD form factor
- M.2
- M.2 SSD size
- 2242 (22 x 42 mm)
- Optical drive type
- No
Graphics
- Discrete graphics card model
- Not available
- On-board graphics card
- Yes
- On-board GPU manufacturer
- Intel
- Discrete graphics card
- No
- On-board graphics card family
- Intel Arc Graphics
- On-board graphics card model
- Intel Arc Graphics 130V
Audio
- Audio chip
- Senary SN6147
- Audio system
- Dolby Atmos
- Number of built-in speakers
- 2
- Speaker power
- 2 W
- Built-in microphone
- Yes
- Number of microphones
- 2
Camera
- Front camera
- Yes
- Front camera resolution
- 1920 x 1080 pixels
- Front camera HD type
- Full HD
- Infrared (IR) camera
- Yes
- Privacy camera
- Yes
- Privacy type
- Privacy shutter
Network
- Top Wi-Fi standard
- Wi-Fi 7 (802.11be)
- Wi-Fi standards
- Wi-Fi 7 (802.11be)
- Mobile network connection
- No
- Antenna type
- 2x2
- WLAN controller manufacturer
- Intel
- Ethernet LAN
- No
- Bluetooth
- Yes
- Bluetooth version
- 5.4
- WWAN
- Not installed
Ports & interfaces
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 2
- HDMI ports quantity
- 1
- HDMI version
- 2.1
- Combo headphone/mic port
- Yes
- USB Type-C DisplayPort Alternate Mode
- Yes
- USB Sleep-and-Charge
- Yes
Performance
- Motherboard chipset
- Intel SoC
Keyboard
- Pointing device
- Touchpad
- Numeric keypad
- No
- Keyboard backlit
- Yes
- Copilot key
- Yes
Software
- Microsoft Copilot
- Yes
- Trial software
- Office
- Operating system installed
- Windows 11 Pro
Processor special features
- Intel® Smart Cache
- Yes
Battery
- Battery capacity
- 54.7 Wh
Power
- AC adapter power
- 65 W
- USB Type-C charging port
- Yes
- USB Type-C required charging power (min)
- 45 W
- USB Type-C required charging power (max)
- 65 W
- USB Power Delivery (USB PD)
- Yes
Security
- Fingerprint reader
- Yes
- Windows Hello
- Yes
- Trusted Platform Module (TPM)
- Yes
- Trusted Platform Module (TPM) version
- 2.0
Certificates
- Certification
- ENERGY STAR,TCO,RoHS
Weight & dimensions
- Width
- 312 mm
- Depth
- 217 mm
- Height (front)
- 1.29 cm
- Height (rear)
- 1.56 cm
- Weight
- 990 g
Packaging content
- AC adapter included
- Yes
