ThinkPad P1 Gen 5 Intel® Core™ i7 i7-12800H Mobile workstation 40.6 cm (16") WQXGA 16 GB DDR5-SDRAM
- Windows 11 Pro
- Intel Core i7-12800H (24MB Cache)
- 40.6 cm (16") WQXGA 2560 x 1600 IPS, NVIDIA RTX A1000 (4GB GDDR6)
- 16GB (4800MHz) DDR5-SDRAM (1 x 16) & 512GB SSD
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Premium power
The sleek design of the ThinkPad P1 Gen 5 mobile workstation hints at what’s inside: a powerful system that offers the professional performance of the latest Intel vPro® platform with Core™ H Series processors and graphics support up to NVIDIA® RTX™ A5500 GPU. Combine this with ISV certification by industry-leading software vendors, and your applications will blaze through heavy workloads.
Learn more about ISV certification.
Visually stunning
Powerful, mobile, and visually stunning, the P1 Gen 5 mobile workstation is the perfect combination of form and function. A liquid metal thermal design improves cooling performance, while the optional Carbon-Fiber Weave looks stunning. This device is designed to be taken out into the world.
Content creator’s dream come true
Boasting a 16″ panel, narrow bezel, and a 16:10 aspect ratio for increased screen real estate, the ThinkPad P1 Gen 5 is designed with the modern user in mind. With its low blue light displays, Dolby Vision®, and X-Rite Factory Color Calibration for crisp, clear images, this device is easy on the eyes.
Keeps your data—& privacy—safe
The ThinkPad P1 Gen 5 laptop starts with our ThinkShield security suite, preloaded to protect your device and data. From discrete Trusted Platform Module (dTPM) to encrypt your data to a fingerprint reader with biometrics for a simple touch log in, and a self-healing BIOS that can restore earlier system settings when needed, we’ve got you covered.
Built to withstand the worst
We use the US Department of Defense's MIL-STD 810H standards to create a balance of reliability and durability for our ThinkPad laptops. We test against 12 standards and more than 200 quality checks to ensure they run in extreme conditions. These tests cover harsh variables like Arctic wilderness and desert dust storms, including temperature, pressure, humidity, vibration, and more.
Specifications may vary depending upon region / model.
Specifications
Design
- Product type
- Mobile workstation
- Product colour
- Black
- Form factor
- Clamshell
Display
- Display diagonal
- 40.6 cm (16")
- Display resolution
- 2560 x 1600 pixels
- Touchscreen
- No
- HD type
- WQXGA
- Panel type
- IPS
- LED backlight
- Yes
- Native aspect ratio
- 16:10
- Anti-glare screen
- Yes
- Display brightness
- 500 cd/m²
- RGB colour space
- sRGB
- Colour gamut
- 100%
- Maximum refresh rate
- 165 Hz
- Contrast ratio (typical)
- 1200:1
Processor
- Processor manufacturer
- Intel
- Processor family
- Intel® Core™ i7
- Processor generation
- 12th gen Intel® Core™ i7
- Processor model
- i7-12800H
- Processor cores
- 14
- Processor boost frequency
- 4.8 GHz
- Performance cores
- 6
- Efficient cores
- 8
- Performance-core Max Turbo Frequency
- 4.8 GHz
- Efficient-core Max Turbo Frequency
- 3.7 GHz
- Processor cache
- 24 MB
- Processor cache type
- Smart Cache
- Processor base power
- 45 W
- Maximum turbo power
- 115 W
Memory
- Internal memory
- 16 GB
- Internal memory type
- DDR5-SDRAM
- Memory clock speed
- 4800 MHz
- Memory form factor
- SO-DIMM
- Memory layout (slots x size)
- 1 x 16 GB
- Memory slots
- 2x SO-DIMM
- Maximum internal memory
- 64 GB
- Memory channels
- Dual-channel
- Non-ECC
- Yes
Storage
- Total storage capacity
- 512 GB
- Storage media
- SSD
- Total SSDs capacity
- 512 GB
- Number of SSDs installed
- 1
- SSD capacity
- 512 GB
- SSD interface
- PCI Express 4.0
- NVMe
- Yes
- SSD form factor
- M.2
- Optical drive type
- No
- Card reader integrated
- Yes
- Compatible memory cards
- SD
Graphics
- Discrete GPU manufacturer
- NVIDIA
- Discrete graphics card model
- NVIDIA RTX A1000
- Discrete graphics card memory
- 4 GB
- Discrete graphics memory type
- GDDR6
- On-board graphics card
- Yes
- On-board GPU manufacturer
- Intel
- Discrete graphics card
- Yes
- On-board graphics card family
- Intel Iris Xe Graphics
- On-board graphics card model
- Intel Iris Xe Graphics
Audio
- Audio chip
- Realtek ALC3306
- Audio system
- Dolby Atmos
- Number of built-in speakers
- 2
- Speaker power
- 2 W
- Built-in microphone
- Yes
- Number of microphones
- 2
Camera
- Front camera
- Yes
- Front camera resolution
- 1920 x 1080 pixels
- Front camera HD type
- Full HD
- Infrared (IR) camera
- Yes
- Privacy camera
- Yes
- Privacy type
- Privacy shutter
Network
- Top Wi-Fi standard
- Wi-Fi 6E (802.11ax)
- Wi-Fi standards
- 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
- Mobile network connection
- No
- Antenna type
- 2x2
- WLAN controller model
- Intel Wi-Fi 6E AX211
- WLAN controller manufacturer
- Intel
- Ethernet LAN
- No
- Bluetooth
- Yes
- Bluetooth version
- 5.1
- Near Field Communication (NFC)
- No
- WWAN
- Not installed
Ports & interfaces
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 2
- HDMI ports quantity
- 1
- HDMI version
- 2.1
- Thunderbolt 4 ports quantity
- 2
- Intel® Thunderbolt 4
- Yes
- Combo headphone/mic port
- Yes
- USB Type-C DisplayPort Alternate Mode
- Yes
- USB Sleep-and-Charge
- Yes
- USB Sleep-and-Charge ports
- 1
Performance
- Motherboard chipset
- Intel SoC
Keyboard
- Pointing device
- ThinkPad UltraNav
- Numeric keypad
- No
- Keyboard backlit
- Yes
- Spill-resistant keyboard
- Yes
- Keyboard language
- English
Software
- Operating system language
- English
- Operating system installed
- Windows 11 Pro
Battery
- Battery technology
- Lithium Polymer (LiPo)
- Battery capacity
- 90 Wh
- Fast charging
- Yes
Power
- AC adapter power
- 170 W
- AC adapter frequency
- 50/60 Hz
- AC adapter input voltage
- 100 - 240 V
- USB Power Delivery (USB PD)
- Yes
Security
- Cable lock slot
- Yes
- Cable lock slot type
- Kensington
- Fingerprint reader
- Yes
- Smart card reader
- No
- Windows Hello
- Yes
- Trusted Platform Module (TPM)
- Yes
- Trusted Platform Module (TPM) version
- 2.0
- Password protection
- Yes
- Password protection type
- BIOS, Power on, SSD, Supervisor
Operational conditions
- Operating temperature (T-T)
- 5 - 35 °C
- Storage temperature (T-T)
- 5 - 43 °C
- Operating relative humidity (H-H)
- 8 - 95%
- Storage relative humidity (H-H)
- 5 - 95%
- Maximum shipping altitude
- 3048 m
Certificates
- Compliance certificates
- RoHS
- Certification
- MIL-STD-810H TÜV
Sustainability
- Sustainability certificates
- ENERGY STAR, EPEAT Gold
Weight & dimensions
- Width
- 359.5 mm
- Depth
- 253.8 mm
- Height
- 17.7 mm
- Weight
- 1.81 kg
