TeraStation TS3430RN NAS Desktop Alpine AL524 2 GB DDR4 16 TB HDD Black
- Home & Home Office NAS Desktop Black
- Total installed storage capacity: 16 TB Number of storage drives supported: 4 HDD & SSD Serial ATA III
- Alpine AL524 2 GHz
- 2 DDR4
- Ethernet LAN
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
Secure, User Friendly Storage Solutions for Small Offices
The TeraStation 3030 solves common small office challenges—such as slow file access, unreliable backups, and costly storage—with an all-in-one NAS. Equipped with NAS-grade hard drives, pre-configured RAID, and a native 2.5GbE port, the TS3030 delivers faster file access, greater reliability, and easy cloud integration—helping teams stay productive and protected without overburdening IT.
Secure Business Network Storage
Secure business-grade NAS with hard drives included, optimized to efficiently store, share, and back up critical data.
Cloud Integration
Sync with Dropbox, Amazon S3, Microsoft Azure, and OneDrive for hybrid cloud setups, boosting data security, backup versatility, and cost efficiency.
Deploy Out of the Box
Arrives pre-configured with RAID for quick deployment.
Quality Engineering, Made in Japan
Precision-crafted with high-quality components and fully TAA-compliant.
Worry-Free Support & Warranty
Includes a 3-year Next Business Day warranty (including hard drives), plus 24/7 US-based support and data recovery services.
Specifications
Storage
- Storage drive capacity
- 4 TB
- Storage drive interface
- Serial ATA III
- Supported storage drive interfaces
- Serial ATA III
- RAID support
- Yes
- RAID levels
- 0, 1, 5, 6, 10, JBOD
- Hot-swap drive bays
- Yes
- Supported file systems
- BTRFS
- Storage drives installed
- Yes
- Total installed storage capacity
- 16 TB
- Number of storage drives installed
- 4
- Number of storage drives supported
- 4
- Installed storage drive type
- HDD
- Supported storage drive types
- HDD & SSD
Processor
- Processor manufacturer
- Annapurna Labs
- Processor family
- Alpine
- Processor model
- AL524
- Processor frequency
- 2 GHz
- Processor cores
- 4
Memory
- Internal memory
- 2 GB
- Internal memory type
- DDR4
Network
- Ethernet LAN
- Yes
- Ethernet LAN data rates
- 1000,2500 Mbit/s
Ports & interfaces
- USB port
- Yes
- USB 2.0 ports quantity
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 2
- Ethernet LAN (RJ-45) ports
- 2
Design
- Chassis type
- Desktop
- Product colour
- Black
Performance
- Type
- NAS
- Device class
- Home & Home Office
- Backup function
- Yes
- Web-based management
- Yes
- On/off switch
- Yes
- Password authentication
- Yes
Power
- Power consumption (max)
- 85 W
- AC input voltage
- 100 - 240 V
- AC input frequency
- 50/60 Hz
Weight & dimensions
- Width
- 429.2 mm
- Depth
- 429.2 mm
- Height
- 43.1 mm
- Weight
- 7.71 kg
- Package width
- 535.9 mm
- Package depth
- 584.2 mm
- Package height
- 200.6 mm
- Package weight
- 12.4 kg
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- 10 - 85 °C
