ATENKVM Cables
15ft. 15' PS/2 KVM Adapter Cable CPU Module
- Keyboard and mouse emulation - keeps your server functioning smoothly when it is disconnected from the switch's KVM port or relocated to different KVM port
- Lifetime firmware upgrades
- Built in 4.5m Cat 5 cable
- Superior video quality - supports resolution of up to 1600 x 1200 within the distance of up to 4.5m
- Hot pluggable - add or remove computers without having to power down the switch.
- Compact size
Special orderPrice on request
- Reply within 1 business day
- Volume & business pricing
- Shipping across Canada & US
Overview
The most cost effective choice for installations with less than 4.5m between server and switch!
The KA7970 USB KVM Adapter Cable connects the KVM switch to the video and USB ports of the target computer. With its small form factor and light weight design, it fits perfectly into most of the rack-mount or desktop servers.
Specifications
Performance
- Product colour
- Black
- Cable length
- 4.5 m
- Keyboard port type
- USB
- Mouse port type
- USB
- Video port type
- VGA
- Console port
- RJ-45
- Connector 1
- 1 x RJ-45 Male with 4.5 m Cat5 cable
- Connector 2
- 1 x USB Male, 1 x HDB-15 Male
- Connector gender
- Male/Male
- Maximum video resolution
- 1600 x 1200 pixels
- Material
- Plastic
Certificates
- Compliance certificates
- RoHS
Packaging data
- Weight
- 240 g
Ports & interfaces
- Ethernet LAN (RJ-45) ports
- 1
Other features
- Dimensions (WxDxH)
- 79.3 x 37 x 15.5 mm
Downloads
